MoTeC Appendices 65
Wiring
This section provides reference material about the Dash Logger's connector
and wiring requirements.
Connector
CDL3 connector 34 pin connector
Mating connector
34 pin AMP connector #65044
Wire Specification
Wire
Wire to suit Dash Logger connector: 22# Tefzel, Mil Spec : M22759/16-22
M22759/16 Wire Ratings (for various wire gauges)
Insulation Material: Tefzel
Conductor: Tin Plated Copper
Voltage Rating: 600 V
Maximum Temperature: 150
°C
Wire Gauge
[AWG] Cross
Sectional Area
[mm2] Max Current
at 100
°C
Ambient [A]
Resistance
[ohm/m] Resistance
[ohm / 1000 ft]
22 0.38 5 0.045 14.0
20 0.61 6 0.028 8.5
18 0.96 9 0.018 5.5
16 1.2 12 0.014 4.3
14 1.9 18 0.009 2.7
12 3.0 24 0.006 1.8
Wire Stripping Tool
Recommended: Ideal Industries 45-2133 stripping tool with LB1195 wire stop
