MoTeC

Appendices

63

Pin

Name

Function

8 V Sensor

7

8V

Sensor 8 V

5 V Sensor

8

5V

Sensor 5 V

0 V Sensor

9

0V

Sensor 0 V

CAN Interface

19

CAN0H

RS232 / CAN 0 High

18

CAN0L

RS232 / CAN 0 Low

27

CAN1H

RS232 / CAN 1 High

26

CAN1L

RS232 / CAN 1 Low

Ethernet

10

E-RX-

Ethernet Receive -

11

E-RX+

Ethernet Receive +

1

E-TX-

Ethernet Transmit -

2

E-TX+

Ethernet Transmit +

RS232

28 RX

RS232

Input

20 TX

RS232

Output
