62 Appendices
CDL3 Pin List by Function
Pin Name Function
Battery Power
34 BAT- Battery Negative
33 BAT+ Battery Positive
Analogue Voltage Inputs
3 AV1 Analogue Voltage Input 1
4 AV2 Analogue Voltage Input 2
5 AV3 Analogue Voltage Input 3
6 AV4 Analogue Voltage Input 4
Analogue Temp Inputs
16 AT1 Analogue Temp Input 1
17 AT2 Analogue Temp Input 2
Digital Inputs
14 DIG1 Digital Input 1
15 DIG2 Digital Input 2
Speed Inputs
21 SPD1 Speed Input 1
22 SPD2 Speed Input 2
23 SPD3 Speed Input 3
Auxiliary Outputs
5 AUX1 Auxiliary Output 1
6 AUX2 Auxiliary Output 2
7 AUX3 Auxiliary Output 3
8 AUX4 Auxiliary Output 4
