Appendix m: connector – MoTeC ADL EDL User Manual
Page 74
72 Appendices
Appendix M: Connector
ADL Mating Connector
Deutsch : AS6-20-35SN
Wire
Wire to suit connector : 22# Tefzel, Mil Spec : M22759/16-22
Crimp Tool
Crimp Tool : M22520/2-01
Positioner for Crimp Tool : M22520/2-07
• Note that the Crimp Contacts are type 22D (needed to set the crimp tool
correctly)
Wire Stripping Tool
The following tool is recommended
Ideal Industries 45-2133 stripping tool with LB1195 wire stop.
Heatshrink Boots
Straight : Racychem 202K153, Hellermann 156-42-G
Right Angle : Racychem 222K153, Hellermann : 1156-4-G
