68 Appendices
16 AUX8 Auxiliary Output 8
8V Sensor
62
8V Sensor 8V
5V Analog Sensor
18
5V Sensor 5V Analog Volt & Analog Temp
28 5V Sensor 5V Analog Volt & Analog Temp
44 5V Sensor 5V Analog Volt & Analog Temp
0V Analog Sensor
17
0V Sensor 0V Analog Volt & Analog Temp
27 0V Sensor 0V Analog Volt & Analog Temp
33 0V Sensor 0V Analog Volt & Analog Temp
40 0V Sensor 0V Analog Volt & Analog Temp
43 0V Sensor 0V Analog Volt & Analog Temp
0V Digital, Switch, Speed
51
0V Sensor 0V Digital, Switch & Speed
56 0V Sensor 0V Digital, Switch & Speed
61 0V Sensor 0V Digital, Switch & Speed
CAN Interface
71 0V
0V CAN
72 8V 8V CAN
73 CANLA CAN LO A (Note that 73 is internally connected to 75)
74 CANHA CAN HI A (Note that 74 is internally connected to 76)
75 CANLB CAN LO B
76 CANHB CAN HI B
RS232
67
TELEM RS232 Telemetry Output
78 TX RS232 Output
79 RX RS232 Input
