MoTeC Overview 21
See Appendix B: Options Summary for details.
Software
The ADL comes with software packages for managing the ADL, analysing the
logged data and monitoring the telemetry link.
The software must be run on an IBM compatible personal computer running
Windows 95/98/Me/NT/2000/XP.
The following software programs are provided:
Dash Manager
Dash Manager is used for configuration, testing, retrieving the logged data
and for general management of the ADL.
An overview of Dash Manager is included latter in this manual. For detailed
information use the Dash Manager help system.
Interpreter
Interpreter is used to analyse the logged data.
Data Logging analysis is covered in a separate manual.
Telemetry Monitor
The Telemetry Monitor software is used to monitor the optional Telemetry link
and allows viewing of the telemetry data in various graphical formats such as
Charts, Bar Graphs and Dial Gauges. It can also show the vehicles current
track position on a track map and compare the current vehicle data to
reference data.
Alarms can also be set to indicate when a particular value, such as Engine
Temperature exceeds a user programmable limit.
BR2Config
This program is used to configure the BR2 beacon receiver via a CAN
connection. BR2 configuration is covered in the BR2 Manual.
