MoTeC Appendices 55
Pullup Resistor : 4700 ohms to 5V
Voltage Range : 0 to 15V
Positive Trigger Threshold : 3.5 V max
Negative Threshold : 1.0 V min
Hysteresis : 0.5 V Min
Update Rate: 100 times / second
Filter Time Constant: 22usec
Digital Input Measurement Methods
Frequency
Resolution 0.1 Hz
Maximum Frequency : 3200 Hz
Rising Edge Triggered
Period 1 usec
Measures period between rising edges
Resolution : 1 usec
Maximum : 32 msec
Period 100 usec
Measures period between rising edges
Resolution : 100 usec
Maximum : 3.2 sec
Pulse Width 1 usec
Measures pulse low time
Resolution : 1 usec
Maximum : 32 msec
Pulse Width 100 usec
Measures pulse low time
Resolution : 100 usec
