MoTeC Overview 13
• Minimum Corner Speed, Maximum Straight Speed and other Min/Max
values.
• Fuel Used, Fuel Usage, Fuel Remaining, Laps Remaining, Fuel Used per
Lap.
General Purpose Calculations:
The ADL also provides a number of general purpose calculations including:
• 2D and 3D Lookup Tables
• User Defined Conditions
• General Purpose Timers
• Mathematics
The user defined conditions or tables can be used to activate items such as a
Thermatic Fan or Gearbox Oil Pump.
Measurement Inputs
The ADL measurement inputs can be connected to a wide variety of sensors.
This allows the ADL to measure vehicle parameters such as: Suspension
Movement, Wheels Speeds, Steering Angle, Engine Temperature etc.
Input Types
The ADL has a number of different input types which are designed to suit the
different types of sensors.
The following inputs are available:
• 20 Voltage Inputs
• 8 Temperature Inputs
• 2 Wide Band Air Fuel Ratio Inputs (Lambda Inputs)
• 4 Switch Inputs
• 4 Digital Inputs
• 4 Wheel Speed
