I-View SDCI-220 Indoor Speed dome - Manual (Page 16)

16
VI. Specification
Model SDCI-220N SDCI-220P
Image Sensor SONY 1/3” Exview II Color CCD
S/N Ratio More Than 50dB (AGC Off)
Resolution Horizontal: 650 TV Lines
Lens 22x Optical Zoom (F1.6, f=3.9~85.8mm)
Digital Zoom 10x (Setup from factory)
Shooting Distance Min. 1 cm (Wide) / 1 meter (Tele)
Min Illumination 0..1 Lux. @F1.6
Tilt /Pan Speed 15 degrees/second
Scan 360 degrees continuously/90 degrees
Preset: 64 presets
Protocol Multi protocol select by dipswitch
Interface/ Baud Rate RS-485 / 2400, 4800, 9600 selectable.
Mount type Ceiling mount for indoor use
Power supply DC 12/1.25A; Max. 20 W
Dimension/Weight Diameter 6 inch/ Approx. 2 Kg
Temperature -10 degree C to 50 degree C
