MULTI-GARD
®
FIBERGLASS RACEWAY
25701 Science Park Drive
Cleveland, Ohio 44122
216-464-3400
1-800-3CARLON (322-7566)
www.carlon.com
Expansion Joints
Expansion Joints allow for thermal expansion and contraction of outerduct.
Fiberglass expansion joints are recommended every 150 feet on bridge crossing
applications.
Part No. Description
Pkg. Qty. Wt. ea.
M _ EC4 4-Cell 6" Stroke
*
*
M _ EC3 3-Cell 6" Stroke
*
*
Pos. 1
Product
Pos. 2
Outerduct
Pos. 3
Pos. 4
Pos.5
Cells
M = Multi-Cell
S = Standard
H = Heavy Wall
B = Bullet Res.
X = Type C PVC
F = Type 40 PVC
E = Expansion C = Coupling
4 = 4-Cell
3 = 3-Cell
Assembly Instructions
The Multi-Gard Fiberglass system is designed for easy assembly:
1. Place plain end of one 20' section into gasketed coupling body 1/2" to the
gasket depth of another 20' section.
2. Check for alignment and apply epoxy to outside of plain end.
3. Push sections together with a firm push by hand until plain end seats fully
into belled end.
