MULTI-GARD
®
FIBERGLASS RACEWAY
www.carlonsales.com
Fiberglass Multi-Cell Fixed Bends with Bell
Multi-Gard fixed bends use the same coupling design as straight sections. All
bends are provided with engineered plastic innerducts to avoid rope cut-through
into adjacent innerducts.
Part No.
Description
Pkg. Qty. Wt. Ea.
M _ _ HN4S 4-cell 1.19 I.D.
*
*
M _ _ HN3S 3-cell 1.50 I.D.
*
*
Pos. 1
Pos. 2
Outerduct
Pos. 3 (A)
Degree
Pos. 4 Radius Pos. 5
Pos. 6
Cells
Pos. 7
Innerduct
M = Multi-Cell
Outerduct
S = Standard
H = Heavy Wall
B = Bullet Res.
3 = 11 _
5 = 22 _
7 = 45
9 = 90
H = 4ft.
N = 4"
4 = 4-Cell
3 = 3-Cell
S = Smooth
Pkg Qty and Wt ea.
Epoxy Kits
Apply epoxy to plain end and bell before insertion for a water tight joint and to
avoid joint pull-out.
Part No. Description
Pkg. Qty. Wt. ea.
MA10EK 10 ox. w/ stick 1
1.50
MA30EK 30 oz. w/ stick 1
2.50
