Multi-gard, Fiberglass raceway, 20' overall length fiberglass multi-cell with bell – Carlon Multi-Gard Fiberglass Product Description User Manual
Page 2
MULTI-GARD
®
FIBERGLASS RACEWAY
www.carlonsales.com
20' Overall Length Fiberglass Multi-Cell with Bell
Part No.
Description
Bell (A)
Dim.
Outerduct
(B)Dim.
Innerduct Dim.
O.D.
Innerduct Dim.
I.D.
Pkg.
Qty
Wt. per 100 ft.
(lbs.)
MSSS4S-
020
4-Cell Standard
.070
4.31
4.14
1.31
1.19
1140'
240
MSSS3S-
020
3-Cell Standard
.070
4.31
4.14
1.66
1.50
1140'
253
MHSS4S-
020
4-Cell
4.39
4.18
1.31
1.19
1140'
338
MHSS3S-
020
3-Cell Heavy Wall
.090
4.39
4.18
1.66
1.50
1140'
340
MBSS4S-
020
4-Cell Bullet Res.
.250
5.00
4.25
1.31
1.19
1140'
450
MBSS3S-
020
3-Cell Bullet Res.
.250
5.00
4.25
1.66
1.50
1140'
450
Standard Multi-Gard supplied with grey and one white tracer innerduct. Add C for
multi-colored innerduct
(3-cell white/grey/orange) (4-cell white/orange/green/grey)
Gross Automation (877) 268-3700 · www.carlonsales.com · [email protected]
