325
EN-8
6. ALIGNMENT MARKS
Put the conductor within the jaws on intersection of
the indicated marks as much as possible (Figure 2) in
order to meet the meter accuracy specifications.
Fig.2
7. MEASUREMENT
7-1. DC CURRENT (DCA) MEASUREMENT
WARNING
Make sure that all the test leads are disconnected with
the meter’s terminal for current measurement.
1. Set the rotary switch to A .
2. Check if the display shows zero in advance. If the
display doesn’t show zero, press ZERO key.
3. Open the clamp and put the tested conductor in
the center of the clamp jaw taking care to comply
with the current flow shown in the label placed
inside the Inductive clamp jaw and indicates.
4. The current value will be indicate on the display
with automatic detection of the appropriate range.
5. If the reading is preceded by the "-" sign check if
the current flow comply with consideration
indicated.
