325
EN-4
3. SPECIFICATIONS
1. Display: 3 3/4 digits LCD with max. reading 3999,
plus decimal point, unit symbol indication.
2. Overload Indication: LCD will show “OL” in the left
highest position.
3. Low Battery Indication: Replace battery immediately
when LCD displays “ ”.
4. Sampling Rate: 2 times per second for digital display.
5. Power Supply: 9V NEDA 1604 IEC 6F22 JIS 006P
battery x 1pc.
6. Battery Life: About 200 hours.
7. Jaws opening: Max. 36 mm.
8. Conductor size: Max. 35mm.
9. Dimension: 218mm(L)x75mm(W)x43mm(H).
10.Weight: About 375g. (Including battery)
11.Accessories : Test Leads
? manual? carrying case ?
battery.
4. ELECTRICAL SPECIFICATIONS
Accuracy:
±
(..%rdg…dgt)at 23
? ±
5
? , below 80? RH
DCA
Range Resolution Accuracy Overload Protection
400A 0.1A ±
(1.5%+5)
600A 1A ±
(2.0%+5)
800A rms
(60 second)
ACA
Range Resolution
Accuracy
50Hz~60 Hz
Overload Protection
400A 0.1A ±
(2.0%+5)
600A 1A ±
(2.5%+5)
800Arms
(60 second)
