Multi-turn actuators SA 07.1 – SA 48.1 / SAR 07.1 – SAR 30.1
AUMA NORM
Operation instructions
No.
Type
Designation
012
E
Notched pin
019
E
Cheese head screw
020
E
Clamping washer
053
E
Countersunk screw
1.0
B
Housing assly.
2.0
B
Flange, bottom assly.
3.0
B
Hollow shaft assly. (without worm wheel)
5.0
B
Worm shaft assly.
5.12
E
Set screw
5.32
E
Coupling pin
5.37
B
Pull rod assly.
5.7
E
Motor coupling
5.8
B
Manual drive coupling assly.
6
E
Worm wheel
9.0
B
Planetary gear assly. for manual drive
10.0
B
Retaining flange assly.
14
E
Change-over lever
15.0
B
Cover for switch compartment assly.
17.0
B
Torque lever assly.
18
E
Gear segment
19.0
B
Crown wheel assly.
20.0
B
Swing lever assly.
22.0
B
Drive pinion II for torque switching assly.
23.0
B
Drive wheel for limit switching assly.
24
E
Drive wheel for limit switching
24.0
B
Intermediate wheel for limit switching assly.
25.0
E
Locking plate
27
E
Screw plug
30.0
B
Handwheel with ball handle assly.
39
E
Screw plug
49.0
1)
B
Motor plug, socket assly.
50.0
B
Cover assly.
51.0
B
Socket carrier assly. (with sockets)
52.0
B
Pin carrier (without pins)
53.0
B
Socket for control
54.0
B
Socket for motor
55.0
B
Socket for protective earth
56.0
B
Pin for control
57.0
B
Pin for motor
No.
Type
Designation
58.0
B
Wire for protective earth
59.0
1)
B
Pin for motor and thermoswitch
in motor plug
60.0
B
Control unit assly. (but without torque head,
without switches)
61.0
B
Torque switching head
70.0
B
Motor
70.1
1)
B
Motor pin carrier
(without pins)
79.0
2)
B
Planetary gearing for motor drive assly.
80.0
3)
B
Output drive form A assly.
(without thread in stem nut)
80.001
3
E
Thrust bearing set
80.3
3)
E
Stem nut form A (without thread)
85.0
3)
B
Output drive B3
85.001
3)
E
Snap ring
90.0
3)
B
Output drive D
90.001
3)
E
Snap ring
100
B
Switch for limit/ torque switching
(including pins at wires)
105.0
B
Blinker transmitter including pins at wires
(without impulse disc and insulation plate)
106.0
B
Stud bolt for switches
107
E
Spacer
151.0
B
Heater
152.1
3)
B
Potentiometer (without slip clutch)
152.2
3)
B
Slip clutch for potentiometer
153.0
3)
B
RWG assly.
153.1
3)
B
Potentiometer for RWG
(without slip clutch)
153.2
3)
B
Slip clutch for RWG
153.3
3)
B
Electronic board RWG
153.5
3)
B
Wires for RWG
155.0
3)
B
Reduction gearing
156.0
3)
B
Mechanical position indicator
160.1
3)
E
Protection tube(without cap)
160.2
3)
E
Cap for stem protection tube
S1
S
Seal kit, small
S2
S
Seal kit, large
Notes:
When placing orders for spare parts, it is essential to mention type of actuator and our commission number (refer to
actuator name plate). Delivered spare parts may slightly vary from the representation in these instructions.
1) SA 16.1 with output speeds of 32 to 216 rpm or SAR 16.1 with output speeds of 32 and 54 rpm without
plug/ socket connector; motor directly wired to pin carrier (No. 52.0) .
2) not available for all output speeds
3) not included in basic equipment
