AWG5000 Series • www.tektronix.com/signal_sources 9
Arbitrary Waveform Generator
AWG5000 Series (AWG5014 • AWG5012 • AWG5004 • AWG5002)
AWG5000 Series Common Features
Waveform File Import Capability Tektronix TDS5000/6000/7000, DPO4000/7000/70000, DSA70000 (*.wfm). TDS3000 (*.wfm)
AWG400s/500s/610/615/710/710B (*.wfm, *.pat, *.seq), DTG5000s (*.DAT) Text data file
(Third party software creation waveform data: MATLAB, MathCad, Excel)
S/W driver for 3rd party S/W IVI-com driver and MATLAB library
Instrument Control/Data Transfer Ports
GPIB
Remote control and data transfer. (Conforms to IEEE-Std 488.1, compatible with IEEE 488.2 and SCPI-1999.0)
Ethernet (10/100/1000Base-T) Remote control and data transfer. (Conforms to IEEE 802.3). RJ-45
Computer System & Peripherals Windows XP Professional, 512 MB SDRAM, 80 GB removable Hard Drive at rear (available front mount kit),
CD-RW/DVD drive at front, included USB compact keyboard and mouse
PC I/O Ports USB 2.0 compliant ports (6 total, 2 front, 4 rear), PS/2 mouse and keyboard connectors (rear panel),
RJ-45 Ethernet connector (rear panel) supports 10/100/1000BASE-T, XGA out
Display Characteristics 10.4 inch, LCD color display with touch screen, 1024 (H)x768 (V) (XGA)
Power Supply 100 to 240 VAC, 47 to 63 Hz
Power Consumption 450 W
Safety UL61010-1, CAN/CSA-22.2, No.61010-1-04, EN61010-1, IEC61010-1
Emissions EN 55011 (Class A), IEC61000-3-2, IEC61000-3-3
Immunity IEC61326, IEC61000-4-2/3/4/5/6/8/11
Regional Certifications
Europe
EN61326
Australia/New Zealand AS/NZS 2064
Physical Characteristics mm/kg lbs/in.
Dimension mm in.
Height 245 9.6
Width 465 18.0
Length 500 19.7
Weight (approx.) kg lbs.
Net19.5 43.0
Net with Package 28.5 62.8
Mechanical Cooling
Required Clearance
Top and Bottom 2 cm 0.8 inch
Side 15 cm 6 inch
Rear 7.5 cm 3 inch
Environmental
Operating Non-operating
Temperature +10º C to +40º C –20º C to +60º C
Humidity 5% to 80% relative humidity (% RH) at up to +30º C, 5% to 90% RH (Relative Humidity) at up to +30º C,
5% to 45% RH above +30º C up to +50º C 5% to 45% RH above +30º C up to +50º C
Altitude Up to 3,048 meters (10,000 feet) Up to 12,192 meters (40,000 feet)
Random Vibration 0.27 G
RMS
, 5 to 500 Hz, 10 minutes per axis 2.28 G
RMS
, 5 to 500 Hz, 10 minutes per axis
Sine Vibration 0.33 mm
p-p
(0.013 inch
p-p
) constant displacement, 5 to 55 Hz NA
Mechanical shock Half-sine mechanical shocks, 30 g peak amplitude, NA
11 msec duration, 3 drops in each direction of each axis
