Atec Pacific-Power_320AMX User Manual
1, 2, or 3ø – linear ac power source, The leader in ac power technology

Standard Features:
•
Advanced Linear Amplifiers Provide Very Low
Voltage Distortion, no Switching Noise, Fast
Voltage and Current Slew Rates, Exceptionally
Low Output Impedance and High Peak
Current Capability
•
1, 2, or 3 Phase Output Form selectable from
front panel or bus command
•
20 to 5,000 Hz. Full Power Bandwidth
Operation – 5Hz to 50KHz small signal
bandwidth, 3dB at 10% of full voltage
•
Precision Voltage Programming – 0.05% with
Continuous Self-Calibration (CSC) engaged
•
True-RMS Metering of Volts, Amps, and Power
•
GPIB (IEEE-488.2) or RS-232 Interface
•
Waveform Library – Arbitrary Waveform
Generator
•
Up to 99 Programs with Associated Transients
for Static and Dynamic Test Applications
•
UPC Studio Software Suite
Available Options:
•
T-versions include external transformer
assembly for higher voltage ranges
•
Programmable Output Impedance
•
Harmonic Analysis and Waveform Synthesis
•
Peak Inrush Capture and Waveform Analysis
(Available on models with UPC3 controller)
•
UPC Test Manager Software
UPC Manager Software Suite
Master the Power of the Wave!
UPC Manager Software
gives you the tools
necessary to quickly
and easily operate your
AC Power Source. With
our graphical interface
control all areas of your
AC Power Source testing
with simple presets, user
prompts, test sequences,
test plans and custom
reports.
Models 320AMX-320AMXT
FREQUENCY CONVERSION
R & D
MANUFACTURING
AEROSPACE
MILITARY
CUSTOM
1, 2, or
3Ø – Linear AC Power Source
T H E P O W E R O F E X P E R T I S E
2,000VA
20-5,000 Hz
Model 320AMX
As a member of Pacific Power’s AMX-Series popular family of high performance
Linear AC Power Sources, the 320AMX offers the same low output voltage noise
and distortion, ease of installation, and high AC waveform fidelity as found in all of
Pacific Power’s Linear AC Power Sources. Control and operational features provide
a high degree of versatility and ease of use for applications ranging from simple,
manually controlled frequency conversion to harmonic testing and sophisticated
programmable transient simulation.
AC TEST POWER
All 320AMX and 320AMXT models are equipped with a powerful micro-controller with the
ability to operate as a fully integrated test system. This enables a variety of power conditions
and transients to be applied to the device under test while metering and analyzing all
output performance parameters. For higher power requirements, refer to the AMX & ASX
series catalog.
FREQUENCY/ VOLTAGE CONVERSION
The 320AMX is an excellent source of stable AC Voltage over the frequency range of 20 to
5,000 Hz (Direct Coupled Range) or 45 to 5,000 Hz (Transformer Coupled AMXT models)
when using the high-end UPC-32 controller. Also available in 1,200 Hz maximum output
frequency when using UPC3 or Manual controller. The output frequency is quartz-crystal
stabilized. Output voltages up to 270V
L-L
in split phase mode and 234V
L-L
in three phase
mode are available on the 320AMX model and up to 600V
L-L
in three phase mode on the
320AMXT model.
PHASE CONVERSION
With the ability to provide either single or two phase output, the 320AMX is a good choice
to convert three-phase line voltage into precisely controlled split (two-phase) or single-
phase output power.
UPC SERIES CONTROLLER
Three controller models are available in both manual and programmable control
version. All controllers provide manual operation from the front panel. Programmable
Controllers may be operated from the front panel or from a remote interface via RS
232 or GPIB.
The Leader in AC Power Technology
An early pioneer in the development solid-state power conversion equipment,
Pacific Power Source continues to develop, manufacture, and market both linear and
high-performance PWM AC Power Sources. Pacific Power Source’s reputation as a
market and technology leader is best demonstrated by its continuing investments in
both research and development and world-wide customer support. With corporate
owned offices in the United States, Germany, the United Kingdom, and China, local
personalized support is always available.
1Ш4
2Ш4
3Ш4
0-338V
L-N
0-600V
L-L
0-338V
L-N
/ 585V
L-L
