3060-MS
© 2012 Pacific Power Source, Inc. Specifications subject to change without notice. DS#43060MS122012 Page 3 of 4
POWER 62.5kVA/50kW for each 3060-MS
VOLTAGE
(Nominal)
Direct Coupled: 0-120/208 V, 3-phase
External
CURRENT RMS 175 A
RMS
/Phase continuous
Pf < 0.8=175A
RMS
/Phase
Pf 1.0=140A
RMS
/Phase
OVERLOAD (KW) 110% for 1 hour, 125% for 10 minutes, 150% for 10
seconds
FREQUENCY 50Hz, 60Hz or 400Hz Fixed settings
47 - 500 Hz Variable
VOLTAGE THD < 1% max. Vthd at 50 or 60Hz
< 2% max. Vthd at 400Hz
LOAD REGULATION ±1% @ 50/60Hz, ±2% @ 400Hz with Automatic Gain
Control (AGC) enabled
LINE REGULATION ±1% maximum for ±10% line voltage change
LOAD TRANSIENT
RESPONSE AND
RECOVERY TIME
150 microseconds for 50% load step and 300
microseconds for 100% load step.
LOAD POWER
FACTOR Delivers full rated kVA into any Power Factor load.
LOAD BALANCE
RESTRICTION None. Each phase is independently regulated
ISOLATION An input transformer with an electrostatic shield
provides isolation between the input and output of the
system.
OVER CURRENT
PROTECTION
Integral electronic current limiting with auto
recovery. Output Circuit Breaker is optional.
AC Output Specifications
FREQUENCY Range 20 to 1000 Hz
Resolution 4 significant digits, e.g. 400.0
Accuracy ±0.01%,
VOLTAGE Range 0 to VMAX
Resolution 0.1 VAC steps.
Accuracy ±0.2% of range +cal.ref.
CURRENT LIMIT Range 0 to I
RMS
max
Resolution ±0.05%
Accuracy ±3%, FS
PROGRAMMABLE
OUTPUT IMPEDANCE
Dynamic output impedance (Zo) is programmable,
± Zo, MAX in 0.1% steps. Zo value in milliohms and
typically results in a ±10% change in output voltage at
maximum rated load current.
OPERATING TEMP Operating: 0º to +40ºC (32º to 104ºF) – Storage: -10º to
+70ºC (+14º to +158ºF)
RELATIVE HUMIDITY 0 to 95% non-condensing
NOISE LEVEL 65 dbA at 3 feet
EFFICIENCY 85 % typical at full load
COOLING/
VENTILATION
Self-Contained fans; bottom intake, top exhaust, 1200
CFM.
HEAT DISSIPATION AT
FULL LOAD
20 kBTU/HR (6 kW/HR)
SERVICE ACCESS Unit is designed for front access. Power Cabling is routed
through either top or bottom knock-outs.
CERTIFICATION CE, ETL (Optional)
ALTITUDE Operating 6000 Ft. Storage 40,000 Ft.
VOLTAGE
(True RMS)
Range 0-354V
L-N
, 0-708V
L-L
Resolution 0.1 VAC to front panel.
0.001 VAC to remote interface.
Accuracy ±0.2% of range +cal.ref.
CURRENT
(True RMS)
Range 4,000Apk
Resolution 0.01A to front panel.
0.001A to remote interface.
Accuracy ±0.2% of range +cal.ref.
POWER Measures True Power (kW), Apparent Power (kVA)
Power Factor and Crest Factor.
Range
1.4MW / 1.4MVA
Resolution 1.0 Watt
POWER/CREST
FACTOR
Calculated and displayed to three significant digits.
INPUT
VOLTAGE
208
VAC∆
±10%
240
VAC∆
±10%
380
VAC∆
±10%
400
VAC∆
±10%
416
VAC∆
±10%
480
VAC∆
±10%
RECOMMENDED
SERVICE CURRENT
175 A
RMS
175 A
RMS
100 A
RMS
100 A
RMS
100 A
RMS
80 A
RMS
INPUT FREQUENCY 47–63 Hz
POWER FACTOR 0.85 lagging typical
PROTECTION Input CB Standard. Slow Turn-On Circuit is provided to
limit inrush current
AC Power Source is protected against Overcurrent, Short
Circuit, and Overtemperature.
AUDIBLE & VISUAL
ALARMS
Alter operator to any conditions requiring attention.
HEIGHT 72" / 1829 mm
WIDTH 36" / 914 mm
DEPTH 30" / 762 mm
WEIGHT 1,557 lbs. / 715 kg
INSTALLATION
CLEARANCE
36" at front of cabinet for service,
12" top, 0" side and rear
/G GPIB Interface, SCPI Commands & IEEE488.2 (standard)
/S RS232 Interface. SCPI Commands, Baudrate up to 38.4
kBps. (Replaces GPIB, no cost option)
UPC-Studio Windows AC Power Source control Software (no cost
option)
UPC Test Manager License (cost option) required for
Avionics or IEC test options listed below:
ABD0100 License for Avionics Test Sequences according to norm
ABD0100.8.1. Requires UPC-Test Manager Option.
A350 License for Avionics Test Sequences according to norm
Airbus A350. Requires UPC-Test Manager Option.
DO160 License for Avionics Test Sequences according to norm
DO160 Version E - Requires UPC-Test Manager Option.
IEC-AC-4XX IEC 61000-4 AC Immunity Test Sequences. Includes 4-11,
4-14, 4-27, 4-28 and 4-34. Excludes 4-13 Option.
SCU/UPC32-413 IEC 61000-4-13 Inter Harmonic Generator. Required to
run 4-13 tests. Includes 4-13 software.
DRIVERS LabView ™ and LabWindows ™ drivers available
Transformer
Options : Consult factory for details.
/CE CE Mark. Includes Output Circuit Breaker (/OCB)
/CSTB Casters
/OCB Output Circuit Breaker
/M99575 Split Phase Output Configurations (50 kw)
/M99583 Split Phase Output Configurations (32 kw)
Typical MS Options
Mechanical Specifications
General Specifications
Protection and Safety
Options for SCU/UPC32
Equipped MS Systems Only
Parameter Settings
(with optional SCU/UPC32)
Measurements
(with optional SCU/UPC32)
Input Power Requirements
