Model 3060-MS
Solid State Frequency Converter
The Model 3060-MS is a high power solid state frequency converter
consisting of one to ten 50 kW/62.5 kVA, 3 phase AC Power Sources. The
MS Series offers reliable voltage and frequency conversion and power
monitoring for facilities power and/or AC power test applications. By
adding the external SCU/UPC-32 Universal Programmable Controller, the
MS Series can be operated as a fully featured programmable AC Power
Source complete with arbitrary waveform generation and AC transient
programming.
Capable of operating as either the master or slave in a multi-cabinet parallel
system. Easy to reconfigure to meet changing test needs.
System Summary:
System Features:
• Voltage and Frequency Conversion.
• Highly Flexible and Expandable Power
Architecture with Unique Master/Slave
Configuration up to 625 kVA.
• Very High Current Capability.
• Low Voltage Distortion.
Included with Standard Delivery:
• 3060-MS Solid State Frequency Converter.
• User Manuals.
62.5kVA
50, 60, 400 or 47-500 Hz
Direct Coupled Output (3Ø): 0-120
L-N
/ 0-208V
L-L
Output Transformer options available for higher
voltage ranges.
T H E P O W E R O F E X P E R T I S E
The 3060-MS is equipped with simple to use front panel controls for set-
ting output voltage and frequency. This panel also provides read back
on both AC input and AC output Frequency, Voltage, Current and Power
as well as diagnostic information on system status and operation. For
general frequency conversion facility power applications, the front pan-
el controls provide all necessary setting and monitoring capabilities. For
AC power test and development applications, the external SCU/UPC-32
programmable controller may be added as an option.
Maximum System Flexibility and Reliability
Control and Monitor Panel
FREQUENCY CONVERSION R & D MANUFACTURING AEROSPACE MILITARY CUSTOM
• Power: 50kV/62.5kVA per Chassis
• Output Voltage 0-120V
L-N
/0-208V
L-L
3 Phase Wye
or Delta. Optional External Output Transformers
Available to meet higher voltage range
requirements.
• Single or Split Phase Output Configurations
Available.
• Current: Paralled Systems to 1750A/Phase
• Frequency Range: 50, 60 or 400Hz fixed , 47-
500Hz Variable or 20-1000Hz Variable with SCU/
UPC32 Option.
Optional SCU/UPC32 M993235 Remote Controller
