Technical Specifications
KeyTek ECAT ® Model E103 Series Control Center
Computer-driven control center and power units required for the opera-
tion of any KeyTek ECAT test system
Virtual Front Panel ™ control 8 x 40 character keyboard entry & LCD display - allows operator to see
vital test parameters without list scrolling
FiberCom ™ fiber-optic Uses KeyTek ECAT software for full computer control of ECAT test equip-
interface & control system ment (user-supplied PC running Windows, 8 MB RAM, one serial port)
Module Bay For one full-width plug-in module or two half-width modules. Up to five
additional bays (for a total of six) and/or S-ECAT for floor-standing
system available (required for more than three docking bays)
Surge V & I monitor ports For waveform monitoring with an external (user-supplied) oscilloscope at
1kV/V and 200A/V;V & I signals supplied from optional AC coupler/
decoupler or KeyTek ECAT modules/options
Input voltage 100V to 240VAC, 50/60 Hz
Typical input current 3.5A @ 100V; 1.5A @ 240V
Operating temperature 15° to 35° C
Operating humidity 10% to 75% non-condensing
Options E103-S - adds oscilloscope trigger for installed surge modules
AC input connectors are available for most national and international standards.
Technical Specifications
KeyTek ECAT ®
Expert Computer-Aided Testing
for pulsed EMI immunity
The KeyTek ECAT ® is a modular, full capability
EMC test system for measuring and analyzing the
vulnerability of telecom, electronic, and electrical
equipment/ components to pulsed EMI hazards,
including EFT, Surge & PQF
™ (Power Quality Failure).
A powerful design and production tool, the KeyTek
ECAT is the premier EMC test system to meet
Telcordia, UL and FCC standards. It features a totally
integrated modular architecture that enables
manufacturers and designers to easily and rapidly
test for all pulsed EMI threats including
pre-compliance, production sampling and
final compliance.
It’s the only EMC test system you’ll ever need.
Tests for pulsed EMI hazards:
EFT, Surge, PQF
™
Ideal test system to address
most applicable EMC &
Telecom standards, including
CE Mark/IEC standards
Easy-to-use Windows-based
application software for quick
implementation of international
& national test routines
Virtual Front Panel ™ retains key
operating parameters during
set up & testing
Multi-level system interlock
architecture provides
maximum safety
Single output port/instant
mode switching
AC Mains current monitoring
Accurate automatic report
generation
Flexible, economically
upgradable architecture
