OUTpUT #2 (cHaRGER)
dc VOLTaGE OUTpUT (2 Years, 23°c ± 5°c)
oUtPUt Voltage: 0 to +15V DC.
oUtPUt aCCUraCy: ±(0.05% + 10mV).
ProgrammIng resolUtIon: 10mV.
reaDbaCK aCCUraCy
1 : ±(0.05% + 3mV).
reaDbaCK resolUtIon: 1mV.
oUtPUt Voltage settlIng tIme: 5ms to within stated accuracy.
loaD regUlatIon: 0.01% + 2mV.
lIne regUlatIon: 0.5mV.
stabIlIty
2 : 0.01% + 0.5mV.
measUrement tIme CHoICes: 0.01 to 10PLC 7 , in 0.01PLC steps.
aVerage reaDIngs: 1 to 10.
reaDIng tIme
1, 8, 9 : 31ms, typical.
transIent resPonse: High Bandwidth Low Bandwidth
transient recovery time 13 <50µs 3 or <80µs 4 <60µs 3 or <100µs 4
transient Voltage Drop <120mV 3 or <150mV 4 <160mV 3 or <200mV 4
remote sense: 1V max. drop in each lead. Add 2mV to the voltage load regulation specification for
each 1V change in the negative output lead due to load current change. Remote sense required.
Integrity of connection continually monitored. If compromised, output will turn off automatically
once settable window (±0 to ±8V) around normal voltage exceeded.
dc cURRENT (2 Years, 23°c ± 5°c)
ContInUoUs aVerage oUtPUt CUrrent:
Channel #1 (battery) oFF:
I = 50W/(V
SET
channel 2 + 6V); 5A max.
Channel #1 (battery) on:
I = (50W – Power consumed by channel #1)/(V
SET
channel 2 + 6V); 5A max.
The power consumed by channel #1 is calculated as:
Channel #1 sourcing current:
Power consumed = (V
SET
channel 1 + 6V) × (current supplied)
Channel #1 sinking current:
Power consumed = 5 × (sink current)
Peak currents can be a maximum of 5A provided the average current is within the above limits.
ContInUoUs aVerage sInK CUrrent:
Channel #1 (battery) oFF:
0–5V: 3A max.
5–15V: Derate 0.2A per volt above 5V. Compliance setting controls sinking.
Channel #1 (battery) on:
Available current = (50W – Power consumed by channel #1)/5; 3A max. (0–5V).
Derate 0.2A per volt above 5V.
soUrCe ComPlIanCe aCCUraCy: ±(0.16% + 5mA) 5 .
ProgrammeD soUrCe ComPlIanCe resolUtIon: 1.25mA.
reaDbaCK aCCUraCy
1 : 5a range: ±(0.2% + 200µA).
5ma range: ±(0.2% + 1µA).
reaDbaCK resolUtIon: 5a range: 100µA.
5ma range: 0.1µA.
loaD regUlatIon: 0.01% + 1mA.
lIne regUlatIon: 0.5mA.
stabIlIty
4 : 0.01% + 50µA.
measUrement tIme CHoICes: 0.01 to 10PLC 7 , in 0.01PLC steps.
aVerage reaDIngs: 1 to 10.
reaDIng tIme
1, 8, 9 : 31ms, typical.
pULSE cURRENT MEaSUREMENT OpERaTION
trIgger leVel: 5mA to 5A, in 5mA steps.
trIgger Delay: 0 to 100ms, in 10µs steps.
Internal trIgger Delay: 15µs.
HIgH/low/aVerage moDe:
measurement aperture settings: 33.3µs to 833ms, in 33.3µs steps.
average readings: 1 to 100.
PUlse CUrrent measUrement aCCUraCy 11 (2 years, 23°C ±5°C):
aperture
accuracy
±(% reading + offset + rms noise 10 )
<100 µs 0.2% + 900 µA + 2 mA
100 µs – 200 µs 0.2% + 900 µA + 1.5 mA
200 µs – 500 µs 0.2% + 900 µA + 1 mA
500 µs – <1 PLC 0.2% + 600 µA + 0.8 mA
1 PLC 12 0.2% + 400 µA + 0 mA
>1 PLC 0.2% + 400 µA + 100 µA
BURST MOdE cURRENT MEaSUREMENT
measUrement aPertUre: 33.3µs.
ConVersIon rate: 2040/second, typical.
Internal trIgger Delay: 15µs.
nUmber oF samPles: 1 to 5000.
transFer samPles aCross Ieee bUs In bInary moDe: 4800 bytes/s, typical.
LONG INTEGRaTION MOdE cURRENT MEaSUREMENT
measUrement tIme 6 : 850ms (840ms) to 60 seconds in 1ms steps.
dIGITaL VOLTMETER INpUT (2 Years, 23°c ± 5°c)
InPUt Voltage range: –5 to +30V DC.
InPUt ImPeDanCe: 2M
Ω typical.
maxImUm Voltage (either input terminal) wItH resPeCt to oUtPUt low: –5V, +30V.
reaDIng aCCUraCy
1 : ±(0.05% + 3mV).
reaDIng resolUtIon: 1mV.
ConneCtor: HI and LO input pair part of Output #2’s terminal block.
measUrement tIme CHoICes: 0.01 to 10PLC
7 , in 0.01PLC steps.
aVerage reaDIngs: 1 to 10.
reaDIng tIme
1, 8, 9 : 31ms, typical.
aC lIne leaKage CUrrent: 450µA @ 110VAC, typ.; 600µA @ 220V, typ.
relay Control Port: 4-channel, each capable of 100mA sink, 24V max. Total port sink capac-
ity (all 4 combined) is 250mA max. Accepts DB-9 male plug.
1 PLC = 1.00.
2 Following 15 minute warm-up, the change in output over 8 hours under ambient temperature, constant load,
and line operating conditions.
3 Remote sense, at output terminals, 0.5A to 5A typical.
4 Remote sense, with 4.5m (15 ft) of 16 gauge (1.31mm
2 ) wire and 1 Ω resistance in each lead to simulate typical
test environment, 1.5A load change (0.15A to 1.65A).
5 Minimum current in constant current mode is 6mA.
6 60Hz (50Hz).
7 PLC = Power Line Cycle. 1PLC = 16.7ms for 60Hz operation, 20ms for 50Hz operation.
8 Display off.
9 Speed includes measurement and binary data transfer out of GPIB.
10 Typical values, peak-to-peak noise equals 6 times rms noise.
11 Based on settled signal: 100µs pulse trigger delay.
12 Also applies to other apertures that are integer multiples of 1PLC.
13 Recovery to within 20mV of previous level.
2302
2306, 2306-pJ
Battery Simulator
Battery/Charger Simulators
