Partial discharge (PD) measurements are a proven method for effective,
non-destructive evaluation of electrical insulation.
The PD2U provides a simple pushbutton interface with an LCD display.
Display modes include a simple PD charge meter with adjustable “needle”
sensitivity, monochrome phase-resolved PD patterns for characterization of
defects, and a scope-like display showing phase-summed charge pulses
superimposed with the applied voltage wave. High voltage is displayed
showing the waveform and calculates Ы, Ы/√2, Urms.
Although the PD2U is a stand-alone unit, it can be connected to a computer
to capture screenshots or to implement remote control of the unit.
A wide range of accessories are offered adapting the PD2U to specific
testing applications and noise conditions.
Measured results are in compliance with IEC 60270.
CIRCUIT
BREAKER
Partial Discharge Measuring
Specifications are subject to change without notice.
Brochure No. 90503
Partial Discharge Detector and
radio interference Voltage testing
testing aPPlications
Model PD2u
• Condition evaluation of insulation
systems
• Quality assurance testing in
manufacturing plants
• Routine testing in a variety of
applications
➤ compact Design
➤ easy to use
➤ Precise results
➤ stand-alone or computer
operated
➤ an economical PD
testing solution
