CopperPro Testing Capabilities
Standard Features (990DSL and 990DSLWT)
• DCV and ACV measurement
• Shorts, grounds and loop resistance with distance conversion
• Resistive fault location (Wheatstone and K-Test)
• Load coil counter with estimated distance to fault and
impedance vs. frequency graph
• Leakage stress test
• Loop device counter
• Tracing tone with four modes
• Voice frequency noise – metallic and power influence
• Voice frequency loss
• Voice frequency longitudinal balance
• Voice frequency tone generator
• Automated POTS AutoTest
• Dial set and non-intrusive line monitor
• Voice frequency terminated and dial-up test macros
(SmartStrap, MyHelper, FED, SASS, DATU, SmartPro)
Optional Features – Wideband TDR (990DSLWT only)
• Wideband noise and level spectral analysis with
interference masks
• Wideband loss
• Wideband longitudinal balance
• Wideband tone generator
• ADSL and XDSL AutoTest for pair qualification
• ADSL verification test for connectivity testing
• Wideband terminated test macros (SmartStrap, MyHelper, FED)
• TDR AutoTest
• TDR pair 1 test
• TDR compare pair 1 and 2
• TDR difference between pair 1 and 2
• TDR pair 1 monitor
• TDR pair 2 to pair 1 crosstalk
• TDR compare pair 1 to stored trace
Physical
Size (H x W x D): approximately 24.9 cm x 13.5 cm x 8.1 cm
(9.8” x 5.3” x 3.2”)
Weight 1.81 kg (4.0 lb.)
Display 320 x 240 pixel graphic LCD with backlight and
adjustable contrast
LED Indicator Charging status indicator (located on side connector panel)
Communication Port RS-232 PC/Printer port (DB-9)
Power
AC Operation Operates from an external AC and 12V vehicle
adapter/chargers
Battery Type Operates from an internal removable NiMH rechargeable
battery pack (installed)
Battery Life A fully charged battery provides approximately 16 hours
of normal use
Battery Recharge Time 2 to 3 hours (in the tester) for a fully discharged
battery pack
Environmental
Operating Temperature -20° to 60°C (-4° to 140°F)
Storage Temperature -40° to 70°C (-40° to 158°F)
Humidity Tolerance 95% (operation without condensation)
Rain Resistance IEC60529 1P02, international protection water dripping
Vibration Random, 2 g, 5-500 Hz
Shock 1 Meter Drop Test (3 ft.)
Altitude 4500 m (15,000 ft.)
Standards Compliance
Analog Transmission
Parameter Measurement
IEEE 743-1995
ADSL Metallic Interface ANSI T1.413-1998
Regulatory Compliance
Safety CSA C22.2 No.1010.1
CE EN 61326 Emissions and immunity Class A; En 61010-1
+ 2nd Ammendment
Specifications
Specifications: Basic 990DSL
Function Range Accuracy
AC Voltage 0 to 250V 1% ± 0.5V
DC Voltage 0 to ±150V 1% ± 0.5V
(R IN =100 kΩ, 10 MΩ) 150 to 300V 2%
DC Loop Current 0 to 120 mA 2% ± 0.3 mA
(430Ω)
Resistance 0 to 100Ω 0.1% ± 0.10Ω
(shorts & grounds) 100Ω to 4 kΩ 0.3% ± 0.10Ω
4 kΩ to 100 MΩ 3%
Leakage Stress 2 kΩ to 100 MΩ 3%
Opens 0 to 3000 ft. (0 to 9144m) 1% ± 5 ft. (1.5m)
3 to 50 kf (914.4 to 15240m) 3%
50 to 80 kf (15240 to 24384m) 5%
Splits 0 to 50 kf (0 to 15240m) 10% of Cable Length
RFL
Fault Resistance 0 to 30 MΩ =
Loop Resistance 0 to 4000Ω =
Resistance to Fault 0 to 100Ω 0.1% RTS ± 0.10Ω
(at rf = 100 kΩ) 100Ω to 4 kΩ 0.3% RTS ± 0.10Ω
K-Test Same as RFL ± 1% ±1Ω
(RTS = Res.To Strap)
Load Coils
Count 0 to 6 ± 1
Distance to first 0 to 12,000 feet ±10% ±500 feet
(0 to 3,658 meters) (152 meters)
Tracing Tone
Frequency 577.5 Hz 0.1%
Level >3.5 Vpp 10%
VF Noise
Impedance 600Ω, 900Ω, Bridged 1%
Filters C, CN, 3k, 15k, Psophometric =
Metallic Noise 0 to 10 dBrn ± 2 dB
10 to 100 dBrn ± 1 dB
Power Influence 40 to 120 dBrn ± 2 dB
VF Loss
Signal Level -40 to +10 dBm ± 0.5 dB (dryline)
± 1.0 dB (dial up single tone)
± 2.0 dB (dial up Smart Tone)
Frequency 100 Hz to 20 kHz 0.1% ± 2 Hz
