Operational Specifications
Function Range Accuracy
AC Voltage 0 V to 220 V, 60Hz 1% ±0.5 V
DC Voltage
(RIN = 100 kV default; VMV
or 10 MV optional) 0 V to 150 V
150 V to 240 V
240 to 300 V 1% ±0.5 V
2%
3%
DC Loop Current (430 W) 0 mA to 120 ma 2% ±0.3 mA
Resistance
(Shorts and Grounds) 0 Ω to 100 Ω
100 Ω to 4 kΩ
4 kΩto ΩM  0.1% ±0.10 
0.3% ±0.10
3%
Leakage Stress 2 kΩ to 999 MΩ 3%
Opens 0 ft to 3000 ft
3 kft to 50 k ft
50 kft to 80 k ft 1% ±5 ft
3%
5%
Splits 0 kft to 50 k ft 10% DTE ±50 ft1
RFL
Fault Resistance (Rf)
Loop resistance
Resistance to Fault
(@ Rf = 100 kΩ)
K-Test Resistance to Fault
0 M Ω to 30 M Ω
0 Ω to 4000 Ω
0 Ω to 100 Ω
100 Ω to 4 k Ω
0 Ω to 4 k Ω
-
-
0.1 % RTS2 ±0.10 Ω
0.3 % RTS2 ±0.10 Ω
1 % RTS2 ± 1 Ω
Load Coils
Count
Distance to First
0 to 6
0 to 12,000 ft
±1
10 % ± 500 ft
Tracing Tone
Frequency
Level
577.5 Hz
>3.5 V peak-to-peak
0.1 %
10 %
VF Noise
Impedance
Filters
Metallic Noise
Power Influence
Power Harmonics
600 Ω, 900 Ω, Bridged
3
C, C-Notched, 3 k Flat, 15 k Flat,
Psopho
0 dBrn to 10 dBrn
10 dBrn to 100 dBrn
40 dBrn to 120 dBrn
-60 dBm to +20 dBm
(50 Hz to 3 kHz)
1 %
-
±2 dB
±1 dB
±2 dB
±2 dB
±2 dB
VF Loss
Signal Level
Frequency
-40 dBm to +10 dBm
100 Hz to 20 kHz
Single Tone: ± 1 dB
SmartTone: ± 2 dB
0.1 % ±2 Hz
C O P P E R P R O S E R I E S I I S P E C I F I C A T I O N S
Function Range Accuracy
VF Longitudinal Balance
Disturbing Frequency
Impedance 0 dB to 70 dB
200 Hz to 2000 Hz
600 Ω, 900 Ω ±2 dB
0.1 %
1 %
Send VF Tone
Frequency
Amplitude (settable)
Impedance
100 Hz to 20 kHz
-20 dBm to +3 dBm
600 Ω, 900 Ω
0.1 %
±0.5 dB (1 dB steps)
1 %
WB/BB Noise/Level
Impedance
Filters
Frequency
100 Ω, 135 Ω, Bridged
4
E, F, G, 1.3 MHz, 20 MHz
10 kHz to 1.2 MHz
5
25 kHz to 18 MHz 6
1 %
-
0.1%, 508.63 Hz multiples
0.1%, 4312.5 Hz multiples
Amplitude +3 dBm to -50 dBm
-50 dBm to -90 dBm
-90 dBm to -105 dBm ±1 dB7 (Bridged = ±3 dB typical)
±3 dB7 (Bridged = ±3 dB typical)
±3 dB typical
7
Noise Floor -140 dBm/Hz typical -
WB/BB Loss
Impedance
Frequency
Magnitude
HDSL2/4 Loop Attenuation
WB/BB Longitudinal Balance
Disturbing Frequency
(Single Tone)
(70 Tone Multi-Tone)
Impedance
Filter
100 Ω, 135 Ω
10 kHz to 1.2 MHz
5
25 kHz to 18 MHz 6
0 dB to 50 dB
50 dB to 90 dB
0 dB to 70 dB
0 dB to 20 dB
20 dB to 40 dB
40 dB to 50 dB
50 dB to 55 dB
25 kHz to 18 MHz
0.25 MHz to 18 MHz
135 Ω, < 1.2 MHz
100 Ω, > 1.2 MHz
1.3 MHz, < 1.2 MHz
20 MHz, > 1.2 MHz
1 %
0.1%, 508.63 Hz multiples
0.1%, 4312.5 Hz multiples
±1 dB
7
±3 dB 7
±2 dB
±3 dB
7,9
±2 dB 7,9
±3 dB 7,9
±3 dB typical 7,9
0.1%, 4312.5 Hz multiples
0.1%, 4312.5 Hz multiples
1 %
-
