Delayed sweep
Trigger modes Free run, line,
external, video
Range
Non-Option 007
1 +2 µs to +65.535 ms
Option 007, sweep time <30 ms –9.9 ms to +65.535 ms
sweep time
≥
30 ms +2 µs to +65.535 ms
Resolution 1 µs
Accuracy ±1 µs
Demodulation
Spectrum demodulation
Modulation type
AM and FM
Audio output Speaker and phone jack
with volume control
Marker pause time 100 ms to 60 s (nominal)
Amplitude specifications, continued
Pulse digitization uncertainty
(Pulse response mode, PRF >720/sweep time)
Log Linear
RBW
≤
1 MHz <1.25 dB pk-pk <4% of ref level
RBW = 2 MHz <3 dB pk-pk <12% of ref level
Standard deviation (RBW <1 MHz) <0.2 dB (nominal)
Time-gated spectrum analysis
Gate delay1 Edge mode Level mode
Range 3 µs to 65.535 ms
≤
0.5 µs
Resolution 1 µs
Accuracy ±1 µs
(From GATE TRIGGER INPUT to positive edge of GATE OUTPUT)
Gate length
Range
1 µs to 65.535 ms
Resolution 1 µs
Accuracy ±1 µs
(From positive edge to negative edge of GATE OUTPUT)
1. Up to 1 µs jitter due to 1 µs resolution of gate delay clock
