300XAC Specifications
Measurement (Total)
Linking Polyphase 3Φ4W
310XAC 320XAC 340XAC 360XAC
Voltage Range (A+B+C)/3
Accuracy (A+B+C)/3 , Calculated and displayed to one significant digit
Frequency Range 0.0 - 1000.0 Hz
Accuracy L ± 0.1 Hz @ 0.0 - 500 Hz
H ± 0.2 Hz @ 501 - 1000 Hz
Current (rms) Range (A+B+C)/3
Accuracy
± (1% of reading + 5 counts) at 40 - 70 Hz
± (1% of reading + 5 counts) at 70.1 - 500 Hz, and output current (r.m.s.) > 0.200 A
± (1% of reading + 5 counts) at 501 - 1000 Hz, and output current (r.m.s.) > 0.300 A
Power (W) Range A Power + B Power + C Power
Accuracy Calculated Value
Power Apparent
(VA)
Range A VA + B VA + C VA
Accuracy Calculated Value
Power Reactive
(Q)
Range A VAR + B VAR + C VAR
Accuracy Calculated Value
Power Factor Range 0 - 1.000
Accuracy Sum P / Sum VA, Calculated and displayed to three significant digits
Measurement (Total)
Linking Parallel DC
310XAC 320XAC 340XAC 360XAC
Voltage Range 0.0 - 420.0 V
Accuracy ± (1% of reading + 2 counts) > 5 V ± (1% of reading + 5 counts) > 5 V
Current (rms) Range 2 0.05 A - 26.00 A 0.05 A - 52.00 A 0.05 A - 104.00 A 0.05 A - 156.00 A
3 0.05 A - 39.00 A 0.05 A - 78.00 A 0.05 A - 156.00 A 0.05 A - 234.00 A
Accuracy
± (1% of reading + 5 counts) x # of Linked Units,
Current > 1.00 A
± (1% of reading + 5 counts)
x # of Linked Units, Current
> 2.00 A
± (1% of reading + 5 counts)
x # of Linked Units, Current
> 3.00 A
Power (W) Range 2 0 W - 2600 W 0 W - 25200 W 0 W -10400 W 0 W - 15600 W
3 0 W - 3900 W 0 W - 7800 W 0 W - 15600 W 0 W - 23400 W
Accuracy ± (2% of reading + 5 counts) x # of Linked Units
Key
L = Low Limit Range L (2) = Low Limit Range 2 Units Linked H (2 ) = High Limit Range 2 Units Linked 2 = 2 Units Linked
H = High Limit Range L (3) = Low Limit Range 3 Units Linked H (3) = High Limit Range 3 Units Linked 3 = 3 Units Linked
