Model 61511 61611 61512 61612 61511+A615103 61611+A615103 61512+A615103 61612+A615103
Output Phase 1 or 3 selectable
Output Rating-AC
Power
12kVA 18kVA 30kVA 36kVA
Each phase 4kVA 6 kVA 10kVA 12kVA
Voltage
Range
0~150V/0~300V
Accuracy 0.2%+0.2%F.S.
Resolution 0.1 V
Distortion *1 0.3% @50/60Hz , 1%@15~1kHz,1.5%@>1kHz
Line regulation 0.1%
Load regulation *2 0.2%
Temp. coefficient 0.02% per degree from 25℃
Max Current (1-phase mode)
RMS
96A / 48A 144A / 72A 240A / 120A 288A / 144A
Peak (CF=4) 384A / 192A 576A / 288A 960A / 480A 1152A / 576A
Max Current (each phase in 3-phase mode)
RMS
32A / 16A 48A / 24A 80A / 40A 96A / 48A
Peak (CF=4) 128A / 64A 192A / 96A 320A / 160A 384A / 192A
Frequency
Range
DC, 15-1.5kHz
Accuracy 0.15%
Phase
Range
0 ~ 360°
Resolution 0.3°
Accuracy <0.8°@50/60Hz
DC Output (1-phase mode)
Power
6kW 9kW 15kW 18kW
Voltage 212V / 424V 212V / 424V 212V / 424V 212V / 424V
Current 48A / 24A 72A / 36A 120A / 60A 144A / 72A
DC Output (3-phase mode)
Power
2kW 3kW 5kW 6kW
Voltage 212V / 424V 212V / 424V 212V / 424V 212V / 424V
Current 16A / 8A 24A / 12A 40A / 20A 48A / 24A
Input AC Power (each phase)
AC type
3-phase, Delta or Y connecting
Voltage range *3 190-250V (Delta: L-L, Y: L-N)
Frequency range 47-63 Hz
Max. current Delta: 80A Y: 70A Delta: 120A Y: 90A Delta: 200A Y: 160A Delta: 240A Y: 180A
Measurement
Voltage
Range
150V / 300V
Accuracy 0.2%+0.2%F.S.
Resolution 0.1 V
Current
Range
128/32/8 A peak 192/48/12 A peak 320/80/20 A peak 384/96/24 A peak
Accuracy (rms) 0.4%+0.3%F.S.
Accuracy (peak) 0.4%+0.6%F.S.
Resolution 0.1 A
Power
Accuracy
0.4%+0.4% F.S
Resolution 0.1 W
Efficiency *4 0.75 (Typical)
Protect UVP, OCP, OPP, OTP, FAN
Interface GPIB, RS-232, USB, Ethernet (standard)
Temperature
Operation
0℃ ~40℃
Storage -40℃~85℃
Humidity 30 %~90 %
Safety & EMC CE
Dimensions (H x W x D) 1163 x 546 x 700 mm / 45.78 x 21.5 x 27.56 inch *5 1163 x 546 x 700 mm / 45.78 x 21.5 x 27.56 inch x 2 units *5
Weight 229.4 kg / 505.29 lbs 242.4 kg / 533.92 lbs 480 kg / 1057.27 lbs 495 kg / 1090.31 lbs
Others 61511 61512 61511 + A615103 61512 + A615103
Waveform Synthesis 40 orders @ 50/60Hz
Harmonic measurement Voltage / Current 40 orders @ 50/60Hz
Programmable impedance 0Ω+200µH ~ 1Ω+1mH
Note*1 : Maximum distortion is tested on output 125VAC (150V RANGE) and 250VAC (300V RANGE) with maximum current to linear load.
Note*2 : Load regulation is tested with sine wave and remote sense.
Note*3 : Models with 277V
LN
/480V
LL
(5 Wires) AC input voltage are available upon request.
Note*4 : Efficiency is tested on input voltage 230V.
Note*5 : Dimension (H X W X D) with wheelsets : 1246x546x700 mm / 49.05x21.5x27.56 inch
All specifications are subject to change without notice. Please visit our website for the most up to date specifications.
SPECIFICATION
