42
Single-Output: 2000 W GPIB
(Continued)
S p e c i f i c a t i o n s
(at 0 ˚ to 55 ˚ C unless
otherwise specified)
6675A- 6675A- 6675A- 6675A
J07 J08 J09 J11
Special Order Special Order Special Order Special Order
Option Option Option Option
Number of outputs 1 1 1 1
GPIB Yes Yes Yes Yes
Output ratings
Output voltage 200 V 100 V 110 V 150 V
Output current 11 A 22 A 20 A 15 A
Programming accuracy at 25 ˚ C ±5 ˚ C
Voltage 0.04%+ 200 mV 120 mV 120 mV 150 mV
Current 0.1%+ 8 mA 15 mA 13.5 mA 11 mA
Ripple and noise
from 20 Hz to 20 MHz
Voltage rms 3.5 mV 1.9 mV 1.9 mV 2.5 mV
Voltge peak to peak 25 mV 16 mV 16 mV 18 mV
Current rms 15 mA 15 mA 13.5 mA 12 mA
Readback accuracy at 25˚C ±5˚C
(percent of reading plus fixed)
System models only
Voltage 0.05%+ 300 mV 180 mV 180 mV 225 mV
±Current 0.1%+ 12 mA 22 mA 20 mA 15 mA
Load regulation
Voltage 0.002% + 7 mV 4 mV 4 mV 6 mV
Line regulation
Current 0.005% + 1 mA 4 mV 4 mV 1 mA
Transient response time Less than 900 µs for the output voltage to recover 100 mV following a
change in load from 100% to 50% or 50% to 100% of the output current
rating of the supply
Supplemental Characteristics (Non-warranted characteristics determined by design and
useful in applying the product)
Average resolution
Voltage 50 mV 30 mV 30 mV 37.5 mV
Current 2.75 mA 4.5 mA 4.5 mA 3.75 mA
OVP 360 mV 215 mV 215 mV 270 mV
Output Voltage programming
response time*
(excluding command 350 ms 195 ms 195 ms 250 ms
programming processing time)
* Full load programming rise/fall time (10% to 90% or 90% to 10%) with full resistive load equal to rated output
voltage/rated output current.
Power Products Catalog 2002-2003 For more detailed specifications see the product manual at www.agilent.com/find/power
Agilent Performance dc Power Supplies speed and accuracy for test optimization
