40
Supplemental Characteristics
for all model numbers
dc Floating Voltage: Output terminals
can be floated up to ±240 Vdc from
chassis ground
Output Common-Mode Noise Current:
(to signal ground binding post)
500 µ A rms, 4 mA peak-to-peak
Remote Sensing: Up to half the rated
output voltage can be dropped in each
load lead. The drop in the load leads
subtracts from the voltage available for
the load.
Command Processing Time: Average time
required for the output voltage to begin
to change following receipt of digital
data is 20 ms for the power supplies
connected directly to the GPIB.
Modulation: (Analog programming of
output voltage and current)
Input Signal:
0 to –4 V for voltage,
0 to 7 V for current
Input Impedance:
60 k Ohm or greater
Input Power: 3,800 VA, 2,600 W at full
load; 170 W at no load
GPIB Interface Capabilities: SH1, AH1, T6,
L4, SR1, RL1, PP0, DC1, DT1, E1, and C0.
IEEE-488.2 and SCPI-compatible
command set
Regulatory Compliance: Listed to UL1244;
certified to CSA556B; conforms to
IEC 61010-1.
Size: 425.5 mm W x 132.6 mm H x 640 mm D
(16.75 in x 5.22 in x 25.2 in)
See page 102 for more details
Weight: Net, 28.2 kg (62 lbs);
shipping, 31.8 kg (70 lbs)
Warranty Period: Three years
Single-Output: 2000 W GPIB
(Continued)
S p e c i f i c a t i o n s
(at 0
˚
to 55
˚
C unless
otherwise specified)
6671A-
6671A-
6671A-
6672A-
6673A-
J03
J04
J17
J04
J03
Special Order
Special Order
Special Order
Special Order
Special Order
Option
Option
Option
Option
Option
Number of outputs
1
1
1
1
1
GPIB
Yes
Yes
Yes
Yes
Yes
Output ratings
Output voltage
14 V
10 V
15 V
24 V
37.5 V
Output current
150 A
200 A
120 A
85 A
45 A
Programming accuracy at 25
˚
C ±5
˚
C
Voltage
0.04%+
14 mV
10 mV
15 mV
25 mV
37.5 mV
Current
0.1%+
90 mA
125 mA
90 mA
60 mA
40 mA
Ripple and noise
from 20 Hz to 20 MHz
Voltage rms
1.5 mV
750 µV
1.5 mV
1 mV
800 µV
Voltage peak to peak
15 mV
9 mV
15 mV
11 mV
9 mV
Current rms
150 mA
200 mA
150 mA
100 mA
40 mA
Readback accuracy at 25˚C ±5˚C
(percent of reading plus fixed)
System models only
Voltage
0.05% +
25 mV
15 mV
27 mV
40 mV
53.5 mV
±Current
0.1% +
110 mA
150 mA
110 mA
100 mA
60 mA
Load regulation
Voltage
0.002%+
600 µV
300 µV
650 µV
650 µV
1.2 mV
Line regulation
Current
0.005%+
7 mA
10 mA
7 mA
7 mA
4 mA
Transient response time
Less than 900 µs for the output voltage to recover 100 mV following a
change in load from 100% to 50% or 50% to 100% of the output current
rating of the supply
Supplemental Characteristics
(Non-warranted characteristics determined by design and
useful in applying the product)
Average resolution
Voltage
4 mV
2.5 mV
4 mV
6 mV
10 mV
Current
40 mA
55 mA
35 mA
22 mA
15 mA
OVP
28 mV
20 mV
30 mV
42 mV
65 mV
Output Voltage programming
response time*
(excluding command
30 ms
35 ms
35 ms
70 ms
130 ms
programming processing time)
*
Full load programming rise/fall time (10% to 90% or 90% to 10%) with full resistive load equal to rated output
voltage/rated output current.
Power Products Catalog 2002-2003
For more detailed specifications see the product manual at
www.agilent.com/find/power
Agilent Performance dc Power Supplies
speed and accuracy for test optimization
