41
Ordering Information
Opt 200 174 to 220 Vac, 47 to 63 Hz
(Japan only)
Opt 230 191 to 250 Vac, 47 to 63 Hz
* Opt 908 Rack-mount Kit (p/n 5062-3977)
* Opt 909 Rack-mount Kit w/handles
(p/n 5063-9221)
Opt 0L2 Extra Standard
Documentation Package
Opt 0B3 Service Manual
Opt 0B0 No documentation package
* Support rails required
Accessories
p/n 1494-0059 Accessory Slide Kit
p/n 1252-3698 7-pin Analog Plug
p/n 1252-1488 4-pin Digital Plug
p/n 5080-2148 Serial Link Cable
2 m (6.6 ft)
E3663AC Support rails for
Agilent rack cabinets
Single-Output: 2000 W GPIB
(Continued)
S p e c i f i c a t i o n s
(at 0
˚
to 55
˚
C unless
otherwise specified)
6673A-
6674A-
6674A-
6675A-
6675A-
J08
J03
J07
J04
J06
Special Order
Special Order
Special Order
Special Order
Special Order
Option
Option
Option
Option
Option
Number of outputs
1
1
1
1
1
GPIB
Yes
Yes
Yes
Yes
Yes
Output ratings
Output voltage
40 V
56 V
50 V
160 V
135 V
Output current
50 A
38 A
42 A
13 A
16 A
Programming accuracy at 25
˚
C ±5
˚
C
Voltage
0.04%+
40 mV
60 mV
60 mV
160 mV
125 mV
Current
0.1%+
35 mA
28 mA
30 mA
10 mA
12 mA
Ripple and noise
from 20 Hz to 20 MHz
Voltage rms
1 mV
1.25 mV
1.25 mV
2.8 mV
2 mV
Voltge peak to peak
10.5 mV
11 mV
11 mV
20 mV
18 mV
Current rms
40 mA
28 mA
25 mA
18 mA
12 mA
Readback accuracy at 25˚C ±5˚C
(percent of reading plus fixed)
System models only
Voltage
0.05%+
60 mV
90 mV
90 mV
240 mV
185 mV
±Current
0.1%+
60 mA
38 mA
42 mA
14 mA
18 mA
Load regulation
Voltage
0.002%+
1.4 mV
2 mV
2 mV
6 mV
4 mV
Line regulation
Current
0.005%+
4 mA
2 mA
2 mA
1 mA
4 mV
Transient response time
Less than 900 µs for the output voltage to recover 100 mV following a
change in load from 100% to 50% or 50% to 100% of the output current
rating of the supply
Supplemental Characteristics
(Non-warranted characteristics determined by design and
useful in applying the product)
Average resolution
Voltage
10.5 mV
14 mV
12 mV
40 mV
34 mV
Current
12.5 mA
9.5 mA
11 mA
3.25 mA
4 mA
OVP
75 mV
100 mV
85 mV
300 mV
242 mV
Output Voltage programming
response time*
(excluding command
130 ms
130 ms
130 ms
280 ms
250 ms
programming processing time)
*
Full load programming rise/fall time (10% to 90% or 90% to 10%) with full resistive load equal to rated output
voltage/rated output current.
Power Products Catalog 2002-2003
For more detailed specifications see the product manual at
www.agilent.com/find/power
Agilent Performance dc Power Supplies
speed and accuracy for test optimization
