Atec Chroma-63200 Series - Manual (Page 6)

Model 63204 63205 63206
Power*1 520W 5200W 650W 6500W 1040W 10400W
Current 0-10A 0-100A 0-18A 0-180A 0-60A 0-600A
Voltage 2.5-500V 1-80V 1-80V
Min. Operating Voltage 2.5V@10A 2.5V@100A 1V@18A 1V@180A 1V@60A 1V@600A
Constant Current Mode
Range 0-10A 0-100A 0-18A 0-180A 0-60A 0-600A
Resolution 2.5mA 25mA 4.5mA 45mA 15mA 150mA
Accuracy 0.1%+0.1%F.S. 0.2%+0.1%F.S. 0.1%+0.2%F.S. 0.1%+0.2%F.S. 0.1%+0.2%F.S. 0.1%+0.2%F.S.
Constant Resistance Mode
Range 0.125-500ohm 5-20000ohm 0.008-32ohm 0.4-1600ohm 0.0025-10ohm 0.125-500ohm
Resolution 12bits 12bits 12bits 12bits 12bits 12bits
Accuracy*2 0.024mho+0.35% 0.08mho+0.1% 0.375mho+0.35% 0.75mho+0.1% 1.2mho+0.35%*4 1.2mho+0.1%
Accuracy*3 (Vin>7V) 0.024mho+0.35% 225u mho+0.35% 0.375mho+0.35% 0.075mho+0.35% 1.2mho+0.35% 0.024mho+0.35%
Constant Voltage Mode
Range 2.5-125V 2.5-500V 1-16V 1-80V 1-16V 1-80V
Resolution 31mV 125mV 4mV 20mV 4mV 20mV
Accuracy 0.05%+0.1%F.S. 0.05%+0.1%F.S. 0.05%+0.1%F.S. 0.05%+0.1%F.S. 0.05%+0.1%F.S. 0.05%+0.1%F.S.
Constant Power Mode
Range 1.25-520W 12.5-5200W 0.36-650W 3.6-6500W 1.2-1040W 12-10400W
Resolution 6.25mW 62.5mW 4.6mW 46mW 22.5mW 225mW
Accuracy 0.5%+0.5%F.S. 0.5%+0.5%F.S. 0.5%+0.5%F.S. 0.5%+0.5%F.S. 0.5%+0.5%F.S. 0.5%+0.5%F.S.
Dynamic mode
Timing
T1&T2 0.025-10mS 1mS-30S 0.025-10mS 1mS-30S 0.025-10mS 1mS-30S
Resolution 1µS 1mS 1µS 1mS 1µS 1mS
Accuracy 1µS+100ppm 1mS+100ppm 1µS+100ppm 1mS+100ppm 1µS+100ppm 1mS+100ppm
Slew Arte 1.6mA-0.4A/µS 16mA-4A/µS 3mA-0.75A/µS 30mA-7.5A/µS 10mA-3A/µS 100mA-25A/µS
Resolution 1.6mA/µS 16mA/µS 3mA/µS 30mA/µS 10mA/µS 100mA/µS
Min. Rise Time 24 µS (typical) 15 µS (typical) 15 µS (typical)
Current
Range 0-10A 0-100A 0-18A 0-180A 0-60A 0-600A
Resolution 2.5mA 25mA 4.68mA 46.8mA 15mA 150mA
Accuracy 0.4%FS 0.4%FS 0.4%FS
Measurement
Voltage Read Back
Range 0-125V 0-500V 0-16V 0-80V 0-16V 0-80V
Resolution 15bits 15bits 15bits 15bits 15bits 15bits
Accuracy 0.05%+0.05%F.S. 0.05%+0.05%F.S. 0.05%+0.05%F.S.
Current Read Back
Range 0-10A 0-100A 0-18A 0-180A 0-60A 0-600A
Resolution 15bits 15bits 15bits 15bits 15bits 15bits
Accuracy 0.1%+0.1%F.S. 0.1%+0.1%F.S. 0.1%+0.1%F.S.
Power Read Back
Range 0-520W 0-5200W 0-650W 0-6500W 0-1040W 0-10400W
Resolution 15bits 15bits 15bits 15bits 15bits 15bits
Accuracy 0.3%+0.3%F.S. 0.3%+0.3%F.S. 0.3%+0.3%F.S.
General
Short Circuit
Current 10A 100A 18A 180A 60A 600A
Size (mm) 440(W)x 353(H)x 644(D) 440(W)x 310(H)x 644(D) 440(W)x 443.7(H)x 644(D)
Weight 58kg 64kg 90kg
Safety & EMC CE CE CE
Se ries
SPECIFICATIONS
