9
Type-N (50 ohms)
N4432A
The characteristic performance in the following table applies to N4432A Option 020 (3.5 mm female connectors on all ports).
Characteristic performance for N4432A Option 020
Frequency range 300 kHz to 10 MHz 10 MHz to 5 GHz 5 to 9 GHz 9 to 13.5 GHz 13.5 to 18 GHz
Parameter
Directivity (dB) 45 52 47 41 42
Source match (dB) 35 41 37 34 34
Reflection tracking (±dB) 0.1 0.06 0.1 0.15 0.14
Transmission tracking (±dB) 2 0.082 0.046 0.062 0.089 0.084
Load match (dB) 2 39 45 40 36 37
3.5 mm
N4433A
The characteristic performance in the following table applies to N4433A Option 010 (3.5 mm female connectors on all ports).
Characteristic performance for N4433A Option 010
Frequency range 300 kHz to 10 MHz 10 MHz to 5 GHz 5 to 9 GHz 9 to 13.5 GHz 13.5 to 20 GHz
Parameter
Directivity (dB) 45 52 47 45 45
Source match (dB) 36 42 39 37 31
Reflection tracking (±dB) 0.1 0.06 0.09 0.10 0.18
Transmission tracking (±dB) 2 0.078 0.045 0.057 0.069 0.160
Load match (dB) 2 39 45 41 39 35
1. When applied power exceeds –7 dBm, calibration results will be degraded from the performance indicated in this table.
1
1
2. Values based on using the PNA Network Analyzer N5230A Option 240 or 245
