Specifications (continued)
Sweep capability
Frequency sweep (sine and dual sine waveforms)
Start point 5 Hz to 80 kHz
Stop point 5 Hz to 80 kHz
Amplitude spot value (balanced) 0 V to 16 V
rms
Amplitude spot value (unbalanced/common) 0 V to 8 V
rms
Frequency sweep (square waveform)
Start point 5 Hz to 30 kHz
Stop point 5 Hz to 30 kHz
Amplitude spot value (balanced) 0 V to 22.6 V
rms
Amplitude spot value (unbalanced/common) 0 V to 11.3 V
rms
Frequency sweep (SMPTE IMD 1:¼ :1/10:1 Waveform)
Start point (upper frequency) 2 to 60 kHz
Start point (lower frequency) 40 to 500 Hz
Stop point (upper frequency) 2 to 60 kHz
Stop point (lower frequency) 40 to 500 Hz
Amplitude spot value (balanced) 0 V to 16 V
rms
Amplitude spot value (unbalanced/common) 0 V to 8 V
rms
Frequency sweep (DFD IEC 60118/IEC 60268 Waveform)
Start point (upper frequency) 3 to 80 kHz
Start point (center frequency) 3 to 79 kHz
Stop point (upper frequency) 3 to 80 kHz
Stop point (center frequency) 3 to 79 kHz
Amplitude spot value (balanced) 0 V to 16 V
rms
Amplitude spot value (unbalanced/common) 0 V to 8 V
rms
Difference frequency spot value 80 Hz to 2 kHz
Voltage sweep
Start point (balanced) 0 V to 16 V
rms
1
Start point (unbalanced/common) 0 V to 8 V
rms
1
Stop point (balanced) 0 V to 16 V
rms
1
Stop point (unbalanced/common) 0 V to 8 V
rms
1
Frequency spot value (sine and dual sine waveforms) 5 Hz to 80 kHz
Frequency spot value (square waveform) 5 Hz to 30 kHz
Frequency spot value (SMPTE IMD 1:¼ :1/10:1 waveform) 40 to 500 Hz (lower frequency), 2 to 60 kHz (upper frequency)
Frequency spot value (DFD IEC 60118/IEC 60268 waveform) 3 to 80 kHz (upper frequency), 3 to 79 kHz (center frequency),
80 Hz to 2 kHz (difference frequency)
DC sweep
Start point (balanced) –22.6 to 22.6 V
Start point (unbalanced/common) –11.3 to 11.3 V
Stop point (balanced) –22.6 to 22.6 V
Stop point (unbalanced/common) –11.3 to 11.3 V
Phase sweep
Start point –180 ° to 179.99 °
Stop point –180 ° to 179.99 °
1. This range is applicable for sine wave only.
