VSG performance
Performance
Sample rate To 125 MSa/s
Bandwidth 100 MHz
Effective DAC resolution 16 bits
Frequency specifications
Frequency range 250 kHz to 6.0 GHz;
also refer to Application Software section
Frequency accuracy ±aging rate; ±temperature effects;
±line voltage effects
Internal time base reference oscillator
aging rate ≤ ±5.0 ppm/10 yrs, < ±1.0 ppm/yr
Temperature effects ±1.0 ppm (0 to 50 °C)
Line voltage effects ±0.1 ppm (nominal), over line
voltage range 5 to –10% (nominal)
Frequency resolution 0.01 Hz
Amplitude specifications
Absolute amplitude accuracy Refer to Application Software section
Output amplitude range Refer to Application Software section
Amplitude resolution 0.02 dB (nominal)
RF Output port Spurious (non-
harmonics) 250 kHz to 3 GHz: < –62 dBc typical (out-of-
band)
3 to 6 GHz: < –56 dBc typical (out-of-band)
RF Output port VSWR 1 1.4:1 nominal (≤ 1.7 GHz)
1.55:1 nominal (> 1.7 to 3 GHz)
1.7:1 nominal (> 3.0 to 4.0 GHz)
1.6:1 nominal (> 4.0 to 6.0 GHz)
RF In/Out port VSWR 1.5:1 nominal (75 MHz to 2.7 GHz; 3.3 to 3.8
GHz)
2.4:1 nominal (4.8 to 6.0 GHz)
1 This specification applies to instruments serial prefix MY4832 or greater, otherwise the specification is 1.7:1
nominal (< 1.4 GHz), 2.3:1 nominal (> 1.4 to 4.0 GHz), 2.4:1 nominal (> 4.0 to 5.0 GHz), 2..2:1 nominal (> 5.0 to 6.0
GHz)
