2
Definitions and
Conditions
N8300A Hardware
Specifications
Specification
Specifications describe the performance parameters covered by the product
warranty and apply over 20 to 30 °C unless otherwise noted. Warranted
specifications include measurement uncertainty calculated with a 95 percent
confidence. Data represented in this document are specifications unless
otherwise noted.
Typical
Represents characteristic performance, which 80 percent of the instruments
manufactured will meet. This data, shown in italics, is not warranted, does not
include measurement uncertainty, and is valid only at room temperature
(approximately 25 °C).
Nominal
The expected mean or average performance, or an attribute whose performance
is by design, such as the 50 Ω connector. This data is not warranted and is
measured at room temperature (approximately 25 °C).
The test set will meet its specification when:
• The test set is within its calibration cycle
• The test set is within the temperature range 20 to 30 °C
• The test set has been turned on for at least 45 minutes
VSA performance
Performance
Quantization 14 bits
Sampling frequency 100 MHz digital down-conversion
Sampling resolution 10 ns
Acquisition buffer 5 ms
Frequency specifications
Frequency range 75 MHz to 4.8 GHz (Option 505);
75 MHz to 6.0 GHz (Option 506)
also refer to Application Software section
Frequency resolution Refer to Application Software section
IF bandwidth Variable to 40 MHz
Amplitude specifications
Maximum safe input level +25 dBm (CW)
Absolute power measurement accuracy Refer to Application Software section
Input amplitude range Refer to Application Software section
