Astro Pneumatic 1442 13 Nut/Thread Setting Hand Riveter Kit with 3pc Metric and 3pc SAE Mandrel/Nosepiece Sets and Rivet Nut Assortment - Manual (Page 3)

Call 1.800.221.9705 for questions concerning performance of the product
or other inquiries.
1442
Product: 1442 Manual
Dimension: A4/page
Date: 2010/07/05
Color:
Black
M100 Y100
第5頁
1442 1442
13" NUT/THREAD SETTING HAND RIVETER KIT WITH
3PC METRIC AND 3PC SAE MANDREL/NOSEPIECE
SETS AND RIVET NUT ASSORTMENT
1442 1442
Unpacking
When unpacking, check the parts diagram and part number listing
on page 3 to make sure all parts are included. If any parts are
missing or damaged, please call your distributor.
MADE IN CHINA
• Patented structure increases power and reduces shock
• Shorter handle with double compound hinges that
maximize leverage
• Includes 13"(330mm) Hand Nut/Thread Setting Riveter
• 6 interchangeable mandrel/nosepiece sets in Metric M5-0.8,
M6-1.0, & M8-1.25 and in SAE 10-24, 1/4-20, & 5/16-18
• Includes 10 pieces of each of the following rivet nuts:
M5-0.8, M6-1.0, M8-1.25, 10-24, 1/4-20, and 5/16-18
• Versatile and powerful hand nut/thread setting riveter, takes
the hard work out of setting rivet nuts
• Ideal for working in hard-to-reach area
• Ergonomic grip for easy operation
• Includes necessary wrenches for quick change of
mandrel/nosepiece sets allowing immediate operation of
riveter with all sizes
第1頁
第6頁 第7頁
第3頁
說明書需要訂裝成一本書
書的頁數順序請依照以下紅字標的頁數
第2頁
1442 1442
FABRIQUÉ EN CHINE
VEUILLEZ NE PAS RETOURNER DE PRODUIT AVANT D'AVOIR
APPELE 1-800-221-9705 POUR OBTENIR DES INSTRUCTIONS
INFORMATIONS PRODUIT:
PRODUCT INFORMATION:
OPERATING INSTRUCTIONS
第4頁
POR FAVOR NO DEVOLVER CUALQUIER PRODUCTO
SIN LLAMAR 1-800-221-9705 PARA OBTENER INSTRUCCIONES
Página 1 Página 2
HECHO A CHINA
INFORMACIÓN DEL PRODUCTO:
Lors du déballage, vérifier que les pièces contenues dans
le schéma et la liste des numéros de pièces de la page 3
sont toutes incluses. Si une pièce est manquante ou abîmée,
veuillez appeler immédiatement votre distributeur.
Déballage
Cuando desempaque el producto, revise el diagrama y la lista
de piezas en página 3 para verificar que se hayan enviado
todas las piezas. De perder piezas o tener piezas dañadas,
favor llamar a su distribuidor inmediatamente.
Desempacado
Modelo: Tipo de Producto: Modelo: Tipo de Producto:
Modèle: Type de Produit: Modèle: Type de Produit:
1442-01
1442-02
1442-03
1442-04
1442-05
1442-06
1442-07
1442-08
1442-09
1442-10
1442-11
1442-12
1442-13
1442-14
1442-15
1442-16 Grip
Handle
Locknut
Bushing
Metal Washer
Screw
Metal Washer
Connecting Bar
Connecting Bar
Bushing
Screw
Metal Washer
Knob
Main Shaft
Main Shaft Drive
Main Body
2
2
4
4
4
4
8
4
2
2
1
1
1
1
1
1 1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
Index
No.
1442-17
1442-18
1442-19
1442-20
1442-21
1442-22
1442-23
1442-24
1442-25
1442-26
1442-27
1442-28
1442-29
1442-30
1442-31
1442-32 Lock Nut
Outer Cylinder
Nosepiece - 6mm-1.0
Mandrel - 6mm-1.0
Nosepiece - 5mm-0.8
Mandrel - 5mm-0.8
Nosepiece - 8mm-1.25
Mandrel - 8mm-1.25
Nosepiece - 10-24
Mandrel - 10-24
Nosepiece - 1/4-20
Mandrel - 1/4-20
Nosepiece - 5/16-18
Mandrel - 5/16-18
Wrench
Wrench
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1 17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
Index
No.
13" NUT/THREAD SETTING HAND RIVETER KIT WITH 3PC METRIC
AND 3PC SAE MANDREL/NOSEPIECE SETS AND RIVET
NUT ASSORTMENT
13" NUT/THREAD SETTING HAND RIVETER KIT WITH 3PC METRIC AND 3PC
SAE MANDREL/NOSEPIECE SETS AND RIVET NUT ASSORTMENT
13" NUT/THREAD SETTING HAND RIVETER KIT WITH 3PC METRIC
AND 3PC SAE MANDREL/NOSEPIECE SETS AND RIVET
NUT ASSORTMENT
13" NUT/THREAD SETTING HAND RIVETER KIT WITH 3PC METRIC
AND 3PC SAE MANDREL/NOSEPIECE SETS AND RIVET
NUT ASSORTMENT
13" NUT/THREAD SETTING HAND RIVETER KIT WITH 3PC METRIC AND 3PC
SAE MANDREL/NOSEPIECE SETS AND RIVET NUT ASSORTMENT
13" NUT/THREAD SETTING HAND RIVETER KIT WITH 3PC METRIC
AND 3PC SAE MANDREL/NOSEPIECE SETS AND RIVET
NUT ASSORTMENT
13" NUT/THREAD SETTING HAND RIVETER KIT WITH 3PC METRIC
AND 3PC SAE MANDREL/NOSEPIECE SETS AND RIVET
NUT ASSORTMENT
13" NUT/THREAD SETTING HAND RIVETER KIT WITH 3PC METRIC AND 3PC
SAE MANDREL/NOSEPIECE SETS AND RIVET NUT ASSORTMENT
13" NUT/THREAD SETTING HAND RIVETER KIT WITH 3PC METRIC
AND 3PC SAE MANDREL/NOSEPIECE SETS AND RIVET
NUT ASSORTMENT
This tool is intended to be used to install metric M5, M6, M8
and SAE 10-24, 1/4-20, 5/16-18 rivet nuts.
• Astro Pneumatic Tool Co. warrants our products to the original user against defective
material or workmanship for a period of 1 year (except where noted on our price
schedule) from the date of 1st use. Astro reserves the right to determine whether the
product failed because of defective material, workmanship or other causes and to charge
back for missing parts. Astro Pneumatic Tool Co., at its discretion, will repair products covered under this warranty free of charge. The distributor should direct the original user
to return the product (with the exceptions listed below) with the distributor’s name,
address, adequate proof of date of purchase or a copy of warranty card, and a short note
explaining the problem. Failures caused by accident, alteration, or misuse are not
covered by this warranty.
• If one part of this product fails, please do not return the entire product. Astro will
replace free of charge component parts of this product that fail within 1 year of first
use by the original user. Items included in this category include but are not limited to kits, hand tool kits and any other product where there are multiple items or
components that make up the unit. Please contact the phone number below in
order to obtain the replacement components covered under warranty.
• Astro Pneumatic Tool Co. or its authorized service representatives must perform all
warranty repairs. Any repair to the product by unauthorized service representatives
voids this warranty. The rights under this warranty are limited to the original user and may
not be transferred to subsequent owners.
• This warranty is in lieu of all other warranties, expressed or implied, including warranties
of merchantability and fitness for a particular purpose. Some states do not allow the
exclusion of limitations of incidental or consequential damages so the above limitations may not apply to you.
1 YEAR LIMITED WARRANTY This tool is intended to be used to install metric M5, M6, M8
and SAE 10-24, 1/4-20, 5/16-18 rivet nuts. • Astro Pneumatic Tool Co. garantit nos produits à son utilisateur d'origine contre tout
matériau déficient ou défaut de fabrication pour une période d'1 an à partir de la date de
la 1ére utilisation. Astro se réserve le droit de déterminer si le produit est déficient à cause
du matériau ou d'un défaut de fabrication ou d'autres causes et de faire payer pour toute pièce manquante. Astro Pneumatic Tool Co., réparera gratuitement, à sa discrétion, les
produits couverts par cette garantie. Le distributeur devrait rediriger l'utilisateur d'origine
pour le renvoi de produit (avec les exceptions énumérées ci-dessous) avec le nom du
distributeur, son adresse et les preuves adéquates de la date d'achat ou une copie de la
carte de garantie et un court message expliquant le problème. Les défaillances
provoquées par accident, altération ou mauvais usage ne sont pas couvertes
par cette garantie.
• Si une partie de ce produit défaille, veuillez ne pas retourner tout le produit. Astro
remplacera gratuitement les parties composant ce produit défaillant dans la première année suivant la première utilisation par l'utilisateur d'origine. Les
éléments inclus dans cette catégorie incluent sans s'y limiter aux kits, kits d'outils à
main et tout autre produit dans lesquels de multiples éléments ou composants
composent l'unité. Veuillez contacter le numéro de téléphone ci-dessous afin
d'obtenir le remplacement des composants couverts par la garantie.
• Astro Pneumatic Tool Co. ou ses représentants officiels du SAV doivent exécuter les réparations sous garantie. Toute réparation d'un produit par un SAV non autorisé annule
cette garantie. Les droits liés à la garantie se limitent à l'utilisateur d'origine et ne peuvent
être transférés à tout autre utilisateur suivant.
• Cette garantie remplace toutes les autres garanties explicites ou implicites et toutes les
garanties implicites de commercia bilité et d'adaptation à un usage particulier. Certaines
provinces n’autorisent pas l’exclusion ou la imitation des dommages circonstanciels ou ortuits, de sorte que l’exclusion ou la limitation ci-dessus peuvent donc
ne pas vous concerner.
GARANTIE A LIMITÉE D'1 AN
This tool is intended to be used to install metric M5, M6, M8
and SAE 10-24, 1/4-20, 5/16-18 rivet nuts.
• Astro Pneumatic Tool Co., Garantiza su producto solo al usuario original contra
materiales o mano de obra defectuosos por 1 año a partir de la fecha del 1ra de uso. Astro se reserva el derecho a determinar si el producto falló a causa de material defectivo,
mano de obra u otras causas y de vuelta a cargo de las piezas que faltan. Astro
Pneumatic Tool Co. a su discreción, sera reparar los productos cubiertos bajo esta garantía
de forma gratuita. El distribuidor debe dirigir el usuario original para devolver el producto
(con las excepciones que se enumeran a continuación) con el nombre del distribuidor,
dirección, una prueba de la fecha de compra o una copia de la tarjeta de garantía, y una
breve nota explicando el problema. Fallas causadas por accidentes,
alteración, o uso indebido no están cubiertos por esta garantía.
• Si faltar una parte de este producto , por favor, no devuelva la totalidad del producto. Astro reemplazará de sin coste para los componentes de este producto que dentro
de 1 año de la primera utilización por el usuario original. Itens incluidos en esta
categoría incluyen, pero no se limitan a piezas, piezas de herramienta manual y
cualquier otro producto que hay itens múltiples o componentes que conforman la
unidad. Por favor, póngase en contacto con el siguiente número de teléfono a fin de
obtener la sustitución de los componentes cubiertos por la garantía.
• Astro Pneumatic Tool Co. o de sus representantes de servicio autorizado debe realizar
todas las reparaciones bajo garantía. Cualquier reparación que el producto no autorizado
por los representantes de servicio los huecos de esta garantía. Los derechos bajo esta
garantía están limitados al usuario original y no podrán ransferirse a
los propietarios posteriores.
• Esta garantía es en lugar de cualquier otra garantía, expresa o implícita, incluidas las garantías de comerciabilidad y adecuación para un propósito en particular. Algunos
estados no permiten la exclusión de las limitaciones de daños incidentales o consecuentes
por lo que las limitaciones no pueden aplicarse a usted.
GARANTÍA A LIMITADA DE UN AÑO
Always wear ANSI approved safety goggles when using this product (Users
and Bystanders). Failure to read and follow all warnings and operating
instructions may result in damages and serious injuries or death.
1. Choose the rivet nut size to be installed.
2. Install the correct size mandrel/nosepiece for the rivet nut to be installed. See
photos and instructions for changing the mandrel/nosepiece and adjustment.
3. Drill a hole in the work product the same size or slightly larger than the outside
diameter of the rivet nut to be installed. 4. To install the rivet nut, open the handles outward as far as possible and thread the
rivet nut clockwise onto the mandrel until reaching the nosepiece.
5. Insert the rivet nut fastened to the riveter into the pre-drilled hole until flush with
the work product, and pull handles inward to secure the rivet nut into the hole. If
the rivet nut is loose in the hole, open the handles outward, turn #13 knob
clockwise, and pull handles inward until the rivet nut is secure in the hole. Repeat
as necessary until the rivet nut is secure in the hole. See adjustment instructions
if necessary. 6. Turn the #13 knob counterclockwise until the mandrel is removed from the rivet
nut. The rivet nut installation is complete if the rivet nut is secure from movement
in the hole.
CHANGING MANDREL/
NOSEPIECE INSTRUCTIONS
ADJUSTMENT INSTRUCTIONS
1. Remove and install the mandrel/nosepiece sets with the wrenches provided in
the riveter kit. Always keep the matched mandrel/nosepiece sets together. The
mandrel can be fastened to the matching nosepiece after removing from the
riveter for convenience and to prevent mismatching.
2. Remove nosepiece from #18 outer cylinder by turning counterclockwise.
3. Loosen #17 locknut and remove #18 outer cylinder from #16 main body by
turning counterclock wise.
4. Remove mandrel from #14 main shaft by turning counterclockwise, while holding
main shaft with wrench.
5. Choose the correct mandrel/nosepiece to be installed.
6. Install mandrel to #14 main shaft by turning clockwise and tighten securely, while
holding main shaft with wrench.
7. Install #18 outer cylinder with #17 locknut to #16 main body by turning clockwise,
adjust to proper depth, and tighten #17 locknut securely. See adjustment
instructions if necessary.
8. Install nosepiece to #18 outer cylinder and tighten securely.
1. Proper adjustment of the riveter is necessary for efficient and easy operation.
2. The adjustment of the riveter will vary, depending on the size and type of rivet nut
being used and the hole size.
3. Adjust the riveter by opening the handles outward as far as possible and turning
the #18 outer cylinder clockwise to increase the number of threads on the mandrel
protruding beyond the nosepiece for larger rivet nuts, and by turning the #18 outer
cylinder counterclockwise for smaller rivet nuts. Fine adjustment can be made by
turning the rivet nut on the mandrel to position the rivet nut closer or further away
from the nosepiece, as long as the mandrel is threaded all the way through the
rivet nut.
4. Always assure that the mandrel is threaded into all threads of the rivet nut to
prevent damage to the threads on the mandrel and/or the rivet nut.
5. If the handles are extended too far outward to provide enough leverage to pull the
handles inward to set the rivet nut, turn the #18 outer cylinder clockwise or turn
the rivet nut counterclock wise slightly to change the handle angle to provide the
proper leverage.
Assembly direction Assembly direction Fasten matching nosepieces and mandrels together when not in use to prevent mismatching the sizes and for convenience M5 M5
M6 M6
M8 M8
Riveter properly prepared for setting rivet nuts
Open handles and thread rivet nut onto mandrel
Turn knob counterclockwise after rivet nut setting is complete to remove riveter from the rivet nut
