2 Installation

Alpha Technologies

2.2

Installing the Unit

2.2.1: CFR 5000

TIP: The seismic brackets can be removed if they are not required by the local code or
you are not in an earthquake zone (See

Tools and Materials Required:

• Fork lift or other means of transporting heavy objects (up to 381 lbs./173kg).

• Screwdriver or power screwdriver with a Philips bit.

•

inch socket wrench.

Procedure:

The unit is shipped attached to a pallet. Use a forklift or pallet jack to transport the unit and

pallet to the installation site.

Remove the packing from around the unit. Unbolt the unit from the pallet.

CFR 5000
attached to

pallet with 5/8
inch bolts.

Slide the unit off the pallet as per the included instruction sheet (017–098–C3). Move the

unit to its final position.

If the seismic brackets are used, mark the position on the floor where the unit will be se-

cured by using the bracket as a template. Drill holes and secure using the appropriate
anchor bolts.
