Page 12: Mounting brackets, 1 introduction 6
1 Introduction
6
Alpha Technologies
1.2
The Alpha CFR 5000 and 5000RM (Continued)
1.3
The Alpha CFR 5000 and CFR 5000RM (Continued)
Feet
If you don’t secure the unit with the seismic
brackets, you can stop the unit from moving
by screwing these down.
CFR 5000 Rack Mount (RM)
This is either the Standard Interface Display (SID) (Section 3.5) or the optional
Intelligent Interface Device (IID) (Alpha manual #018–029–B0–001).
Fans
These four fans cool the unit. They must not be blocked.
ALARM
OFF
MANUAL
START
OUTPUT LOAD
O VER LOA D
1 00 %
7 5%
5 0%
2 5%
LINE P RESENT
LINE FAILURE
SERVICE
LO W BATTER Y
WA RN IN G
LO W BATTER Y
SH UTD OW N
TEST
Mounting
Brackets
These brackets
allow rack mount-
ing. They are
factory config-
ured to fit in a 19
inch rack. To fit in
a 23 inch rack,
remove and then
reverse them.
