2 Installation 14
Alpha Technologies
2.2 Installing the Unit (Continued)
5 If the brackets are not used, remove the cover and the front panel as described in Section
5.4, Step 1, “Remove the Front Panel and the Cover.”
DANGER:
1) There are dangerous voltages inside the unit when the cover is removed.
2) When removing or attaching the cover, do not let it touch the battery terminals, battery
wires or other internal components.
7 Reattach the cover and the front panel.
8 To stop the unit from moving, screw down the feet until they are solid against the floor.
Installation finished
6 Remove the bracket by unscrewing the 3 phillips
screws attaching the bracket to the chassis.
