39
4. Camera description
4.1 Exterior view
1 – Network connection (Ethernet), RJ45
2 – Power supply, 12 VDC, 5.5 x 2.1 mm
circular connector
4.2 Interior view
3 – Reset button
4 – Status LEDs (P, S & L)
5 – Lens
6 – Camera module
7 – Fixing screws for camera module
1
2
7
3
4
5
6
7
4
