29
A description of the different steps can be found in the following table.
To get to the next step in the “QUICK INSTALL” menu, select “NEXT” in the display.
“BACK” returns you to the previous step.
Function Description Standard
value
Shutter / WDR /
AE reference AES exposure control settings
Shutter:
Auto: Automatic setting of exposure time
1/30s-1/10000s: Fixed setting of exposure time
WDR Function for improving image quality when
subject to extreme image contrasts (WDR –
Wide Dynamic Range). Image noise is
increased when activated.
OFF: Function deactivated
ON: Function activated
AE REFERENCE: Determines the brightness as a
reference for amplification and
exposure time, utilizing the mean
value…
AVERAGE: ... of the overall video
image.
CENTER: ... of the middle area of
the video image.
SPOT: ... the middle of the video
picture.
AUTO
OFF
AVERAGE
WHITE
BALANCE White balance settings
AWB:
Auto White Balance
White balance calculations are dynamically
and continuously performed in the
2700~9500K range.
ATW:
Auto White Balance
White balance calculations are dynamically
and continuously performed in the
1800~10500K range.
PTL:
Push-To-Lock
White balance is performed after pressing the
“Enter” button on the back of the camera and
the value is stored permanently.
AWB
