ABUS TVVR20001 - Manual (Page 90)

PTZ control
28
Pattern Settings
Patterns are defined tours from position to position that
are accessed in sequence on the PTZ camera. Patterns
are recorded live. The system saves the parameters
used whilst you move and adjust the cameras in se-
quence to the corresponding positions at a defined
speed.

Select the camera in the control panel, then click on
“Pattern Settings” in the pop-up menu:
1. Select the pattern number.
2. Click on “Run Record” to start the pattern recording.
3. Using the control panel, adjust the camera position
and settings that you wish to record as a pattern.
4. The recording is made until “Stop Record” is clicked.
Note

Start the recorded pattern by calling up the
pop-up menu (right-click in the live view of the
PTZ camera).
 Click on “Run Pattern” and click on the desired
pattern. The PTZ camera now starts moving to
the individual positions. After running through
the entire pattern, the process is started again.
