Only use zone 2 of the detector, as the internal tamper
contacts TS1-2
are deactivated in this way.
14. Configuration
(factory default setting)
Fig. 1
Abbreviations
Description
Abbreviations
Description
CB
Terminal connector strip
TS1 - 2
Internal tamper contacts
RS
Reed switch
eTS3
External tamper contact
NC
Normal closed contact
eS1 - 2
External switch contacts
NO
Normal open contact
X
GB
