Parts List:
ITEM
QTY.
PART NO.
DESCRIPTION
MATERIAL
1
1
28277-01A
GUARD
RUBBER
2
1
28278-01F
SLEEVE
ALUMINUM
3
1
28283-01J
LINK
STAINLESS STEEL
4
1
200873-01G
PIN
STAINLESS STEEL
5
6
42878-02F
STUD
STAINLESS STEEL
6
1
200275-01D
SCREW
STAINLESS STEEL
7
1
90290-07D
BALL
STAINLESS STEEL
8
1
28282-01A
BODY
ALUMINUM
9
12
90290-06F
BALL
STAINLESS STEEL
10
1
84081-43K
RETAINING RING
STAINLESS STEEL
11
1
200279-01K
SPRING
STAINLESS STEEL
12
1
28291-01B
LOCK PIN
STAINLESS STEEL
13
1
28289-01F
CRANK
STAINLESS STEEL
14
1
71988-40G
WASHER
STAINLESS STEEL
15
1
200874-01J
SPACER
ALUMINUM
16
1
67992-12D
COTTER PIN
STAINLESS STEEL
17
1
00518B
O-RING
NITRILE
18
1
200293C
BACKUP RING
NITRILE
19
1
28287-01K
BEARING
TEFLON
*20
1
203750-01B
HANDLE
ALUMINUM
21
1
28284-01G
RETAINER
STAINLESS STEEL
22
1
67584-05C
LOCK WASHER
STAINLESS STEEL
23
1
67603-05A
HEX HEAD BOLT
STAINLESS STEEL
* 24
1
205595-01F
FOLDING HANDLE
STAINLESS STEEL
*25
1
90292-17J
TORSION SPRING
STAINLESS STEEL
*26
1
203749-01F
PIVOT SCREW
STAINLESS STEEL
27
1
28290-01D
POPPET STEM PIN
STAINLESS STEEL
28
1
28279-01G
STEM, POPPET
ALUMINUM
29
1
200277-01B
WAVE WASHER
STAINLESS STEEL
30
1
01140A
O-RING
NITRILE
31
1
28276-01C
NOSE SEAL
ALUM. & POLYURETHANE
32
1
00779K
O-RING
NITRILE
33
1
28280-01E
POPPET
ALUMINUM
34
6
200276-01C
FLAT HEAD SCREW
STAINLESS STEEL
*Parts are replaced by ______, ______for rigid handle styles
351GF-15
