2 1/2 PIPE DIAMETERS
MIN RECOMENDED
LENGTH SPOOL
INLET
INLET
OUTLET
OUTLET
3
4
1
2
R
o
ll
Se
a
l
®
™
R
o
ll
Se
a
l
®
™
1 COUPLER FOR GROOVED PIPE
2 SPOOL STRAINER ASSEMBLY (WITH CONE)
3 100-42 MAIN VALVE, GROOVE X FLANGE
4 100-42 MAIN VALVE, GROOVE X GROOVE
Recommended Pipe layout
6" - 12" Grooved style 100-42
