© 2003-2014 Acuity Brands Lighting, Inc. All Rights Reserved. Rev. 01/21/14. Specifications subject to change without notice.
PAGE 2 OF 3
AF-8-OPEn-DTT
DIM
EN
SIO
N
AL D
AT
A
N
OT
ES
8” AF
Open Reflector
Horizontal Lamp, Double Twin-Tube
PH
OTO
M
ET
RY
All dimensions are inches (centimeters) unless otherwise noted.
ORDERING NOTES
1.
Not available with finishes.
2.
Multi-volt electronic ballast capable of operating on any voltage from 120V
through 277V, 50 or 60 Hz.
3.
.
4.
Not available with 13DTT.
5.
Available in 120V or 277V only.
6.
.
7.
For compatible RELOC systems, refer to
8.
Not available with emergency options.
9.
Meets codes that require in-fixture disconnect.
10. Must specify wattage. Ex.: WRL32
Aperture:
8 (20.3)
Ceiling opening: 8-7/8 (22.5)
Overlap trim:
9-1/4 (23.4)
Lens recess:
2-5/8 (6.7)
5
8 [1.6]
678 [17.4]
1413
16 [37.6]
15 78 [40.3]
