GOTHAM ARCHITECTURAL DOWNLIGHTING | 1400 Lester Road Conyers GA 30012 | P 800.315.4982 | gothamlighting.com
© 2003-2014 Acuity Brands Lighting, Inc. All Rights Reserved. Rev. 01/21/14. Specifications subject to change without notice. PAGE 2 OF 3
AF-8-OPEN-TRT
DIM
EN
SIO
N
AL D
AT
A
EL
EC
TR
IC
AL
N
OT
ES
8” AF
Open Reflector
Horizontal Lamp, Triple-Tube
PH
OTO
M
ET
RY
All dimensions are inches (centimeters) unless otherwise noted.
ORDERING NOTES
1. Not available with finishes.
2. Multi-volt electronic ballast capable of operating on any voltage from 120V
through 277V, 50 or 60 Hz.
3. For additional ballast types, refer to TECH-250 .
4. Not available with 13W or 57W.
5. Available in 120V or 277V only.
6. For dimensional changes, refer to TECH-140 .
7. For compatible RELOC systems, refer to TECH-110 .
8. Not available with emergency options.
9. Meets codes that require in-fixture disconnect.
10. Must specify wattage. Ex.: WRL32
834 [22.2]
Aperture: 7-7/8 (20.1)
Ceiling Opening: 8-7/8 (22.5)
Overlap Trim: 9-1/4(23.5)
Lens Recess: 2.5 (6.4) min.
15 78 [40.3]
14 34 [37.4]
Two-lamp
version shown.
Annual*
Energy
Cost
$5.44
$5.08
$5.93
$5.92
Lamps
(1) 32W TRT
(1) 42W TRT
(2) 32W TRT
(2) 42W TRT
Lamp
Lumens
2400
3200
4800
6400 0.98
1.00
0.96
0.95
Input
Watts
36
46
69
94
* Comparative yearly lighting energy cost per 1000 lumens
LER.DOL
44
47
40
41
Ballast
Factor
ENERGY (Calculated in accordance with NEMA standard LE-5A)
