6” af cross baffle reflector – Gotham 6 AF Cross Baffle Reflector SpecSheet User Manual
Page 2
© 2005-2014 Acuity Brands Lighting, Inc. All Rights Reserved. Rev. 01/21/14. Specifications subject to change without notice.
PAGE 2 OF 3
AF-6-XBAFFLE-TRT
DIM
EN
SIO
N
AL D
AT
A
N
OT
ES
6” AF
Cross Baffle Reflector
Horizontal Lamp, Triple-Tube
PH
OTO
M
ET
RY
All dimensions are inches (centimeters) unless otherwise noted.
ORDERING NOTES
1.
Multi-volt electronic ballast capable of operating on any voltage from 120V
through 277V, 50 or 60 Hz.
2.
.
3.
Not available with 13W.
4.
Available in 120V or 277V only.
5.
6.
For compatible RELOC
7.
Not available with emergency options.
8.
Meets codes that require in-fixture disconnect.
9.
Must specify wattage. Ex.: WRL32
Aperture:
6-1/4 (15.9)
Ceiling opening: 7-1/8 (18.1)
Overlap trim:
7-1/2 (19.1)
Lens recess: 4 (10.2)
6-7/16
(16.4)
15-7/8
(40.3)
13-5/8
(34.6)
