8” af cross baffle reflector – Gotham 8 AF Cross Baffle Reflector SpecSheet User Manual
Page 2
© 2005-2014 Acuity Brands Lighting, Inc. All Rights Reserved. Rev. 01/21/14. Specifications subject to change without notice.
PAGE 2 OF 3
AF-8-XBAFFLE-TRT
DIM
EN
SIO
N
AL D
AT
A
N
OT
ES
8” AF
Cross Baffle Reflector
Horizontal Lamp, Triple-Tube
PH
OTO
M
ET
RY
All dimensions are inches (centimeters) unless otherwise noted.
ORDERING NOTES
1.
Multi-volt electronic ballast capable of operating on any voltage from 120V
through 277V, 50 or 60 Hz.
2.
3.
Not available with 13W or 57W.
4.
Available in 120V or 277V only.
5.
For dimensional changes, refer to
6.
For compatible RELOC systems, refer to
7.
Not available with emergency options.
8.
Meets codes that require in-fixture disconnect.
9.
Must specify wattage. Ex.: WRL32
Aperture:
7-7/8 (20.1)
Ceiling Opening: 8-7/8 (22.5)
Overlap Trim:
9-1/4 (23.5)
Lens recess: 4-1/2 (11.4)
812 [21.5]
14 34 [37.4]
15 78 [40.3]
