11” laf square lens – Gotham 11 LAF Square Lens SpecSheet User Manual
Page 2
© 2006-2014 Acuity Brands Lighting, Inc. All Rights Reserved. Rev. 04/10/14. Specifications subject to change without notice.
PAGE 2 OF 3
LAF-11-SquARE-LEnS
DIM
EN
SIO
N
AL D
AT
A
11” LAF
Square Lens
Wet Location, Horizontal Lamp, Double Twin-Tube or Triple-Tube
PH
OTO
M
ET
RY
All dimensions are inches (centimeters) unless otherwise noted.
13-1/4 (33.7)
24 (61.0)
Aperture:
10-1/8 (27.0)
Ceiling opening:
11-1/4 (28.6)
Overlap trim:
11-5/8 (29.5)
6 (15.2)
